Product Description
Lift-Rite LF C-10210 manual pallet jack load roller assembly features a 1-3/4 inch diameter by 3 inch width machined steel roller with sealed ball bearings, designed for Lift-Rite and Big Joe L-50 manual pallet jacks. Cross-references include LF C-10210-A and 10210.
Compatibility: Fits pallet jacks made by Lift-Rite, model LF C-10210. Alternate model: LF C10210; LF C 10210. SKU: LF C-10210
Specifications
Dimensions & Physical Properties
| Roller Diameter | 1-3/4 inch |
| Roller Width | 3 inch |
| Number of Bearings | 2 sealed ball bearings per assembly |
Material & Construction
| Roller Material | Machined steel |
| Hub Material | Steel |
| Bearing Material | Hardened steel |
Part Numbers
| Direct Replacement Part Number | LF C-10210 |
| Cross-Reference Part Numbers | LF C-10210-A, LF 10210, 10210 |
| Supersedes | LF C-10210-A |
| Compatible Equipment | Lift-Rite L-50, L-50 CHEP, L-50 CHEP 4-Way; Big Joe L-50 |
Frequently Asked Questions
Q: What is the LF C-10210 load roller assembly?
A: The LF C-10210 is a complete load roller assembly featuring a 1-3/4 inch diameter by 3 inch width machined steel roller with sealed ball bearings. It supports the load forks on manual pallet jacks.
Q: Which pallet jack models does the LF C-10210 fit?
A: The LF C-10210 is compatible with Lift-Rite L-50 CHEP 4-way pallet jacks and Big Joe L-50 manual pallet jacks. Cross-references include LF C-10210-A and 10210.
Q: How many bearings does the LF C-10210 assembly include?
A: The LF C-10210 assembly includes 2 sealed ball bearings, one on each side of the roller. Sealed bearings protect against dirt and moisture contamination in the load roller.
Q: What material is the LF C-10210 roller made from?
A: The roller is constructed from machined steel, providing high strength and durability to support heavy loads and withstand continuous use in material handling operations.
Q: What are the cross-reference part numbers for the LF C-10210?
A: Cross-references for LF C-10210 include LF C-10210-A, LF 10210, and 10210. The assembly supersedes the earlier LF C-10210-A designation. Use LF C-10210 as the primary SKU when ordering.
