Product Description
Thrust taper roller bearing assembly for electric lift truck mast applications. Features 35 mm bore, 101 mm outer diameter, and 29 mm width. Pre-lubricated and sealed design extends service life in demanding warehouse, outdoor, and cold storage environments. Direct replacement for factory-spec TB 1009 bearing. High-grade bearing steel with anti-corrosion coating provides durability and load capacity for mast column thrust forces. Compatible with Voltas, Godrej, ACE, and Toyota electric lift trucks and mast systems.
Specifications
Dimensions & Measurements
| Bore Size | 35 mm |
| Outer Diameter | 101 mm |
| Width | 29 mm |
Type & Design
| Bearing Type | Thrust taper roller bearing, single row |
| Seal Type | Sealed |
| Lubrication | Pre-lubricated |
Material
| Material Specification | Bearing steel (Chrome steel per Bajaj) |
Part Numbers
| Cross-Reference Part Numbers | TB 1009, IMB TB1009, Bajaj TB 1009 |
| Direct Replacement For | TB 1009 |
| Equivalent Part Numbers | 02396561 (Bajaj Bearings), IMB TB1009 |
Applications & Compatibility
| Compatible Makes | Voltas, Godrej, ACE, Toyota |
| Application | Electric lift truck mast bearing, mast column thrust support |
Frequently Asked Questions
Q: What are the specifications for SKU 220027085 bearing assembly?
A: The 220027085 is a bearing assembly for electric lift truck mast applications. This is a thrust taper roller bearing, single row, with seal and pre-lubricated. Key specifications include 35 mm bore, 101 mm outer diameter, and 29 mm width. The bearing is constructed from high-grade bearing steel with anti-corrosion coating for extended service life. It is interchangeable with OEM part number TB 1009 and cross-references include IMB TB1009 and Bajaj TB 1009. This bearing is directly compatible with Voltas, Godrej, ACE, and Toyota forklift models requiring this mast bearing.
Q: Which electric lift truck models use the 220027085 bearing assembly?
A: The 220027085 bearing assembly is compatible with Voltas, Godrej, ACE, and Toyota forklifts and electric lift trucks that require the TB 1009 or equivalent mast bearing. The bearing supports vertical mast movement and load transfer in the mast column assembly. Verify your lift truck model and current bearing part number before ordering. If your equipment uses OEM designation TB 1009, the 220027085 is a direct replacement.
Q: What are the cross-reference and equivalent part numbers for the 220027085?
A: The 220027085 bearing assembly cross-references include OEM part number TB 1009, IMB TB1009, Bajaj TB 1009, and equivalent part number 02396561 (Bajaj Bearings). These designations all refer to the same thrust taper roller bearing with 35 mm bore and 101 mm outer diameter. If your equipment documentation or bearing housing lists any of these part numbers, the 220027085 is a compatible replacement.
Q: What material is the 220027085 bearing constructed from?
A: The 220027085 bearing assembly is constructed from high-grade bearing steel (chrome steel per Bajaj specification) with anti-corrosion coating. The bearing races and rollers are precision-machined and hardened to withstand the thrust loads generated by the lift truck mast and load. The anti-corrosion coating protects against rust and oxidation in warehouse, outdoor, and cold storage environments.
Q: What is the expected service life of the 220027085 bearing?
A: The 220027085 bearing is pre-lubricated and sealed to extend service life. Bearing lifespan depends on duty cycle, load frequency, environmental conditions, and maintenance practices. In normal warehouse service, the bearing should provide several years of operation. Signs of bearing failure include grinding noise, mast movement resistance, or lateral play in the mast column. Replace the bearing if you observe these symptoms or if the mast does not raise and lower smoothly.
Q: Is the 220027085 bearing pre-lubricated and sealed?
A: Yes, the 220027085 bearing assembly is pre-lubricated and sealed. The sealed design protects the bearing races and rollers from contamination and moisture ingress. Pre-lubrication means the bearing is ready for service without additional grease application. The seal integrity is critical to bearing longevity. If the seal is damaged or leaking, replace the bearing assembly to prevent premature failure.
