Product Description
Polyurethane Wheel (95 Shore D) for electric lift truck and pallet jack applications. 3.23 inch diameter, 1.62 inch tread width, 2.49 inch hub width, 2.02 inch bearing diameter. Red polyurethane tread with white polypropylene hub, non-marking, chemical and oil resistant, cross-referenced to WH-720-95D and WH-734-95D, and compatible with standard electric lift truck caster assemblies.
Specifications
Compatibility
| Compatible Equipment | Electric lift trucks, pallet trucks, material handling caster assemblies |
Material
| Wheel Tread Material Specification | Polyurethane, industrial grade, Shore D 95 hardness |
| Finish | Molded polyurethane tread, injection molded hub |
Part Numbers
| Manufacturer Part Number | WH-720-95D |
| Equivalent Part Numbers | WH-734-95D, WH-730-95D |
Performance
| Floor Protection | Non-marking tread, suitable for finished concrete and warehouse floors |
Frequently Asked Questions
Q: What are the key dimensions of this polyurethane wheel?
A: This wheel has a 3.23 inch diameter, 1.62 inch tread width, 2.49 inch hub width, and 2.02 inch bearing diameter. These dimensions fit standard electric lift truck and pallet jack caster assemblies.
Q: What equipment types is this wheel compatible with?
A: This wheel is designed for electric lift trucks and pallet trucks. The dimensions and 95 Shore D hardness make it suitable for standard caster assemblies on these material handling equipment types.
Q: What are the cross-reference part numbers for this wheel?
A: This wheel cross-references to WH-720-95D, WH-734-95D, and WH-730-95D. These part numbers may be used interchangeably depending on your supplier and OEM documentation.
Q: What does 95 Shore D hardness provide?
A: 95 Shore D is a firm polyurethane hardness rating that provides excellent wear resistance and load support. This rating is suitable for heavy-duty electric lift truck and pallet truck applications on hard floors.
Q: What are the material properties of the tread and hub?
A: The tread is industrial-grade polyurethane with 95 Shore D hardness, molded for wear resistance. The hub is injection-molded white polypropylene. The combination is non-marking, chemical resistant, and oil resistant for warehouse environments.
Q: How do I verify this wheel fits my equipment?
A: Measure your equipment caster assembly bore diameter and confirm it matches 2.02 inches. Also verify that your wheel mounting accepts the 1.62 inch tread width. Confirm the 3.23 inch diameter matches your lift truck or pallet jack specification before ordering.
