Link for Pallet Jacks

Frequently Asked Questions

Q: What is the A000036536 link and where is it used?
A: The A000036536 is a structural arm component that forms part of the scissor linkage assembly in lift tables and pallet jacks. It connects the hydraulic cylinders to the fixed frame and transmits lifting force from the cylinders to the platform. It is used across Crown, Toyota, Hyster, and Yale equipment.

Q: What are the material and dimensional specifications for this link?
A: The A000036536 is a fabricated steel link constructed from ASTM A500 Grade B structural tubing with welded end brackets. Overall length is 18.75 inches, with a 2-inch by 1.5-inch rectangular tube cross-section. Wall thickness is 0.125 inches. Pin bore diameter at each end is 0.75 inches.

Q: What failure modes should I watch for?
A: The A000036536 can fail by cracking at weld joints near the end brackets, bending or buckling from overload, or breaking at the pin bore holes. Symptoms include platform tilt, unusual noise during lifting, reduced maximum lift height, and visible cracks in the tube or welded areas. Do not operate equipment with a cracked link.

Q: What is the typical service life of this link?
A: With proper maintenance and correct load centering, the A000036536 has a service life of 12 to 18 years. Uneven loading or frequent overload conditions reduce lifespan to 6 to 9 years. Rust in the welds caused by poor drainage can accelerate failure to 4 to 5 years.

Q: What cross-reference parts are available for this link?
A: The A000036536 is equivalent to Crown part number 171298 and Linde part number 9023-04-1225. Always verify weld position, end bracket geometry, and pin bore diameter when cross-referencing, as structural dimensions determine load capacity.
