Armature for Hyster EV-100
HY 388230
Couldn't load pickup availability
- Expert support & fitment help
- 30-day returns
- Fast Shipping
Compatibility
|
Make |
|
|---|---|
|
Model |
|
Visit our diagram page for part references to popular models
Product Description
Hyster OEM ARMATURE EV-100 AUX (HY 388230): Auxiliary armature for Hyster electric lift trucks utilizing EV-100 motor control systems; engineered for 24–36VDC applications, direct replacement for Hyster cross-referenced models. Constructed with copper alloy commutator and silicon steel laminations to SAE and ASTM standards. Includes keyway and bi-directional mounting for continuous duty industrial electric drive circuits.
Specifications
Material & Construction
| Core Construction | Laminated silicon steel per ASTM A677 |
Part Numbers & Compatibility
| Make | Hyster |
| Model | E25XM2, E30XM2, E35XM2, E40XMS2, E80-120XL3, E50XL |
| Part Number | HY 388230 |
| Cross-Reference Part Numbers | HY388230, 388230 |
| Equivalent Part Numbers | TotalSource 388230, EV-100 AUX Armature |
| Compatible Equipment | Hyster Electric Lift Trucks equipped with EV-100 control systems |
| Cross Reference Part Numbers | HY388230, 388230 |
Electrical Specifications
| Intended Voltage Range | 24VDC to 36VDC |
Performance Specifications
| Efficiency Rating | 86% at rated load |
Additional Specifications
| Motor Circuit | Auxiliary (EV-100 series) |
| Maximum Allowable RPM | Up to 3,400 RPM |
| Service Factor | 1.15 |
| Description | Hyster OEM ARMATURE EV-100 AUX (HY 388230): Auxiliary armature for Hyster electric lift trucks utilizing EV-100 motor control systems; engineered for 24–36VDC applications, direct replacement for Hyster cross-referenced models. Constructed with copper alloy commutator and silicon steel laminations to SAE and ASTM standards. Includes keyway and bi-directional mounting for continuous duty industrial electric drive circuits. |
