Barrett Lift Switch for WRPN60/80 Trucks
BR 27350-020
Couldn't load pickup availability
- Expert support & fitment help
- 30-day returns
- Fast Shipping
Compatibility
|
Make |
|
|---|---|
|
Model |
|
Visit our diagram page for part references to popular models
Product Description
Barrett BR 27350-020 high-speed lift/lower/horn switch for WRPN60/80 electric lift truck applications. Triple-pole, single throw actuator with momentary spring-return. Rated for 24VDC nominal, 10A maximum, silver alloy contacts, compatible with Barrett WRPN60/80 series.
Compatibility: Fits pallet jacks made by Barrett, model WRPN 60/80. Alternate model: WRPN60/80. SKU: BR 27350-020
Specifications
Electrical
| System Voltage | 24VDC nominal system compatibility |
| Contact Rating | 10A at 24VDC |
Part Numbers
| Manufacturer Part Number | BR 27350-020 |
| OEM Part Number | BR 27350-020 |
| Compatible Models | Barrett WRPN60, Barrett WRPN80 |
Frequently Asked Questions
Q: What voltage and amperage rating does the BR 27350-020 have?
A: The BR 27350-020 is rated for 24VDC nominal system voltage with a maximum contact rating of 10 amperes at 24VDC.
Q: What functions does the BR 27350-020 control?
A: The BR 27350-020 is a high-speed lift/lower/horn switch that controls lift, lower, and horn functions on Barrett WRPN 60/80 electric lift trucks. It features triple-pole, single throw construction with momentary spring-return action.
Q: Is the BR 27350-020 compatible with WRPN60 and WRPN80 models?
A: Yes. The BR 27350-020 is compatible with both Barrett WRPN60 and WRPN80 electric lift truck models. Verify that your truck system operates at 24VDC before ordering.
Q: What contact material is used in the BR 27350-020?
A: The BR 27350-020 features silver alloy contacts, which provide reliable conductivity and resistance to arcing and wear in 24VDC lift truck applications.
Q: What does momentary spring-return mean?
A: Momentary spring-return means the switch returns to its neutral position automatically when you release the actuator. This design prevents unintended continuous operation and enhances operator safety.
