Product Description
Barrett BR 27522 Battery Discharge Indicator is designed for 24VDC electric pallet jacks and lift trucks. It features an LED bar display for state-of-charge, 52 mm face diameter, 64 mm depth, and panel mount configuration. Cross-reference part numbers include Barrett 27522-49 and A-27522-51.
Specifications
Electrical
| Nominal Voltage | 24VDC |
| Operating Voltage Range | 24VDC to 36VDC |
Material & Construction
| Construction | Enclosure molded polymer with integrated electronics |
Part Numbers
| OEM Part Number | BR 27522 |
| Cross-Reference Part Numbers | Barrett 27522, BR27522, 27522-49, A-27522-51, 27522-12 |
| Supersedes/Replaces Part Numbers | Replaces Barrett 27522-49, supersedes A-27522-51, equivalent to 27522-12 |
| Compatible Equipment | Barrett electric pallet jacks and electric lift trucks specified for 24V BDI |
Frequently Asked Questions
Q: What is the BR 27522 battery discharge indicator and what voltage does it support?
A: The BR 27522 is a Barrett OEM battery discharge indicator designed for 24VDC electric pallet jacks and lift trucks. It displays the state-of-charge via an LED bar display to help operators monitor battery capacity during operation.
Q: What are the physical dimensions and mounting type of the BR 27522?
A: The BR 27522 has a 52 mm face diameter and 64 mm depth. It is designed for panel mount configuration, meaning it mounts flush through a control panel or dash with fasteners from the back. Verify your panel opening dimensions match before ordering.
Q: What cross-reference part numbers are equivalent to BR 27522?
A: The BR 27522 is cross-referenced as BR27522, Barrett 27522, 27522-49, A-27522-51, and 27522-12. The unit replaces Barrett 27522-49 and supersedes A-27522-51. Use these part numbers for sourcing and equipment documentation reference.
Q: Which Barrett electric pallet jacks and lift trucks use the BR 27522?
A: The BR 27522 is compatible with Barrett electric pallet jacks and electric lift trucks with 24VDC systems. Verify your equipment uses 24VDC power before ordering. Contact us with your model or serial number for specific compatibility confirmation.
Q: How do I troubleshoot a BR 27522 that is not displaying state-of-charge?
A: Check the 24VDC power supply to the indicator. Verify the battery is charged. Inspect wiring connections at the back of the unit for loose or corroded terminals. If the LED display remains blank after voltage and connection verification, the gauge may require replacement.
