Product Description
Barrett BR 27522-000 Battery Discharge Indicator is a 24VDC panel-mount device engineered for electric lift truck applications, utilizing an LED bar graph for state-of-charge indication. Compatible with Barrett electric pallet jacks and associated models, and directly supersedes/replaces or cross-references multiple prior manufacturer part numbers.
Specifications
Electrical
| Nominal Operating Voltage | 24VDC |
| Control Circuit Voltage | 24 volts DC |
Part Numbers
| OEM Part Number | BR 27522-000 |
| Manufacturer Part Number | BR 27522 |
| Cross-Reference Part Numbers | 27522, BR27522 |
| Supersedes/Replaces | A-27522-51 |
| Equivalent Part Numbers | BR 27522-008a |
Frequently Asked Questions
Q: What is the BR 27522-000 Battery Discharge Indicator designed for?
A: The BR 27522-000 is a 24VDC panel-mount battery discharge indicator engineered for electric lift trucks. It features an LED bar graph display that shows the state of charge of the battery system, allowing operators to monitor available battery capacity during operation.
Q: What operating voltage does the BR 27522-000 require?
A: The BR 27522-000 operates on 24 volts DC. The control circuit voltage is also 24 volts DC. Verify your lift truck battery system matches this voltage before ordering.
Q: What equipment is the BR 27522-000 compatible with?
A: The BR 27522-000 is compatible with Barrett electric pallet jacks and associated lift truck models equipped with 24VDC battery systems. Check your equipment specifications to confirm compatibility.
Q: What are the cross-reference part numbers for the BR 27522-000?
A: The BR 27522-000 cross-references to part numbers 27522 and BR27522. It supersedes and replaces part number A-27522-51. The equivalent part BR 27522-008A can also be used as a replacement.
Q: Is the BR 27522-000 a new or rebuilt unit?
A: The BR 27522-000 is an original equipment manufacturer (OEM) new part. If you need a rebuilt alternative, the BR 27522-008A is a rebuilt equivalent that performs the same function.
Q: What does the LED bar graph display on the BR 27522-000 indicate?
A: The LED bar graph provides a visual state-of-charge indication for the lift truck battery. The number of illuminated LEDs indicates the remaining battery capacity, helping operators determine when recharging is necessary.
