Product Description
Hyster HY 3012285 bushing is a precision-machined bronze component designed for electric lift truck applications. Manufactured from SAE 660 bronze with oil-impregnated self-lubricating properties, this bushing features a 1.250 inch outer diameter, 1.000 inch inner diameter, and 2.00 inch length. Suitable for high-load environments in Hyster electric lift trucks, it supersedes part 345047 and is equivalent to 3021844.
Specifications
Material & Construction
| Surface Finish | Machined finish, 32 µin Ra |
Part Numbers & Compatibility
| OEM Part Number | HY 3012285 |
| Manufacturer Part Number | 3012285 |
| Cross-Reference Part Numbers | Replaces 1328817, supersedes 345047, equivalent to 3021844 |
Frequently Asked Questions
Q: What material is the HY 3012285 bushing made from?
A: The HY 3012285 is manufactured from SAE 660 bronze with oil-impregnated self-lubricating properties. This material provides excellent wear resistance and self-lubrication in high-load environments.
Q: What are the dimensions of the HY 3012285 bushing?
A: The HY 3012285 features a 1.250 inch outer diameter, 1.000 inch inner diameter, and 2.00 inch length. The machined finish provides a 32 microinch Ra surface.
Q: What parts does the HY 3012285 replace or cross-reference to?
A: The HY 3012285 supersedes part number 345047 and is equivalent to part number 3021844. It is also suitable as a replacement for part 1328817 in compatible Hyster electric lift trucks.
Q: Why does the HY 3012285 have self-lubricating properties?
A: The oil-impregnated self-lubricating properties of the SAE 660 bronze reduce friction and wear in high-load applications typical of electric lift truck environments. This extends service life and reduces maintenance requirements.
