Product Description
Raymond RA171666 Button - Lift/Lower is an OEM momentary push-button switch designed for Raymond electric lift trucks. Features include a 24VDC rated SPST-NO contact, industrial thermoplastic actuator, and compatibility with OEM panel cutout. No interchangeable or supersession part numbers supplied by manufacturer sources.
Specifications
Electrical Specifications
| Contact Rating | Rated 5A at 24VDC resistive load |
| Control Voltage | 24VDC nominal |
| Connection Type | Tab terminals 0.187 inch quick-connect |
Material & Construction
| Button Material | Industrial-grade thermoplastic actuator |
| Base Material | Nylon PA6 with glass fiber reinforcement |
Mechanical Specifications
| Button Projection | 0.25 inch nominal projection above panel |
Part Numbers
| OEM Part Number | RA171666 |
| Manufacturer Part Number | 171666 |
Performance Specifications
| Duty Cycle | Rated for continuous momentary switching up to 120 cycles/hour |
Frequently Asked Questions
Q: What is the RA 171666 button used for on Raymond electric lift trucks?
A: The RA 171666 is a momentary push-button switch that controls lift and lower functions on Raymond electric lift trucks. It is an SPST-NO (single pole single throw normally open) contact switch rated for 24VDC operation.
Q: What are the electrical specifications for the RA 171666?
A: The RA 171666 is rated at 5A at 24VDC resistive load. It operates at 24VDC nominal with an acceptable voltage range of 22 to 28VDC. The switch features tab terminals with 0.187 inch quick-connect connections and a nominal button projection of 0.25 inch above the panel.
Q: What is the button material and mounting specification for the RA 171666?
A: The button has an industrial-grade thermoplastic actuator designed for durability in material handling environments. It is designed for standard OEM panel cutouts and features industrial-strength construction to withstand frequent operator use.
Q: Does the RA 171666 have any interchangeable or supersession part numbers?
A: According to Raymond OEM documentation, there are no interchangeable or supersession part numbers supplied by the manufacturer for the RA 171666. Use the exact OEM part number RA 171666 when ordering replacement buttons.
Q: Can the RA 171666 button be used on Raymond lift trucks other than the original equipment?
A: The RA 171666 is engineered specifically for Raymond electric lift trucks with 24VDC control systems. Verify that your truck model uses 24VDC nominal voltage and that the panel cutout dimensions match before ordering. Do not attempt to use this button on equipment with different voltage systems.
