Product Description
Raymond RA 1049977 is a right-hand closed wheel plate for Raymond 7400 series electric lift trucks, designed for use with a 5 x 2.88 inch load wheel and side shift function, featuring compatibility with OEM axle and spacer components.
Specifications
Material & Construction
| Plate Material | Heavy-gauge steel, industrial duty |
| Load Wheel Size | 5 x 2.88 inch |
| Bearing Compatibility | Designed for use with bearings installed in load wheel; see RA 632-043-A for integrated bearing reference |
| Functionality | Side shift function |
Part Numbers
| Part Number | RA 1049977 |
| Cross-Reference Part Numbers | Supersedes RA 1049979; left-hand equivalent RA 1049976 |
| Compatible Models | Raymond 7400, 7420, 7440 series (closed toe configuration) |
Performance
| Operating Application | Side-shifting load wheel carrier assemblies on Raymond electric lift trucks |
| Wheel Plate Configuration | Right-hand closed wheel plate |
Frequently Asked Questions
Q: What equipment does the RA 1049977 wheel plate fit?
A: The RA 1049977 is a right-hand closed wheel plate designed for Raymond 7400, 7420, and 7440 series electric lift trucks. It is configured for 5 x 2.88 inch load wheels and is compatible with OEM axle and spacer components for these models.
Q: What is the material composition of the RA 1049977 wheel plate?
A: The RA 1049977 is manufactured from heavy-gauge steel with industrial-duty construction. This material provides durability and load-bearing capability for material handling applications.
Q: Are there any cross-reference or superseded part numbers for the RA 1049977?
A: Yes. The RA 1049977 supersedes the earlier part number RA 1049979. The equivalent left-hand version is RA 1049976. Verify your equipment orientation before ordering to ensure correct fitment.
Q: What is the difference between the RA 1049977 and RA 1049976?
A: The RA 1049977 is a right-hand closed wheel plate, while the RA 1049976 is the left-hand equivalent. Both fit the same Raymond 7400 series models but are mirror images to accommodate different axle configurations.
Q: Will the RA 1049977 work with non-OEM bearings or spacers?
A: The RA 1049977 is designed for use with OEM axle and spacer components. Cross-compatibility with aftermarket or non-OEM parts should be verified by comparing bearing bore diameter and spacer width specifications to ensure proper fit and load distribution.
