Product Description
Hyster HY 16540 electrical connector is designed for battery circuit assembly in J1.60XMT-2.00XMT electric lift trucks. Features include dual terminal high-current interface, industrial thermoplastic housing, and panel-mount configuration. No known cross-reference part numbers.
Specifications
Electrical
| Circuit Rating | Designed for high current battery connections (nominally 48VDC systems) |
Part Numbers
| OEM Part Number | HY 16540 |
| Manufacturer Part Number | HY 16540 |
| Compatibility | Compatible with Hyster J1.60XMT-2.00XMT (J160 Series) electric lift trucks |
Performance
| Service Factor | Nominal service factor of 1.00 for battery circuit applications |
Frequently Asked Questions
Q: What is the HY 16540 electrical connector designed for?
A: The HY 16540 is an electrical connector designed for the battery circuit assembly in Hyster electric lift trucks. It provides a dual-terminal high-current interface between the battery pack and the truck electrical system for power distribution.
Q: Which Hyster electric lift trucks are compatible with the HY 16540 connector?
A: This connector is compatible with Hyster J1.60XMT-2.00XMT series electric lift trucks, also designated as J160 series models. Verify your truck model number before ordering to confirm compatibility.
Q: What are the electrical and physical specifications of the HY 16540?
A: The HY 16540 features a panel-mount configuration with industrial thermoplastic housing for durability. It is designed for high-current battery connections in nominally 48 VDC systems with a service factor of 1.00 for battery circuit duty.
Q: What materials is the HY 16540 connector made from?
A: The connector housing is constructed of industrial thermoplastic for chemical and impact resistance. Contact terminals are engineered for high-current carrying capacity and corrosion resistance in battery service applications.
Q: Are there cross-reference part numbers for the HY 16540 connector?
A: No known cross-reference part numbers exist for this connector. Use only the original equipment manufacturer part number HY 16540 when ordering replacements to ensure correct electrical specifications and physical fit in your truck battery circuit.
