Product Description
Heavy-duty battery connector type SB175, 175A, 600V continuous rating, constructed of impact-resistant polycarbonate housing with silver-plated copper contacts. Designed for electric lift trucks, fits 1/0 AWG cable, features mechanical keying to prevent voltage/color mismatch, rated for 10,000 mating cycles. Industry standard red housing for 24V systems.
Specifications
Electrical
| Continuous Current Rating | 175A continuous |
| Voltage Rating | 600V AC/DC |
| Wire Gauge Compatibility | Accepts 1/0 AWG cable |
Material & Construction
| Insulator Material Specification | Polycarbonate, UL94 V-0 flame retardant |
Part Numbers
| Manufacturer Part Number | DS228886 |
Performance Specifications
| Connector Mating Cycle Life | Rated for up to 10,000 mating cycles |
Frequently Asked Questions
Q: What are the electrical specifications of the DS228886 battery connector?
A: The DS228886 is an SB175 type battery connector rated for 175A continuous current at 600V AC/DC. It features silver-plated copper contacts for reliable electrical conductivity and is compatible with 1/0 AWG cable. The red housing indicates this connector is designed for 24V system applications and is industry standard for electric lift truck battery installations.
Q: Which electric lift trucks use the DS228886 connector?
A: The DS228886 is a standard SB175 battery connector suitable for 24V electric lift truck battery systems. It fits equipment from major OEM manufacturers including Crown, Toyota, Raymond, Yale, Hyster, and similar brands that use 1/0 AWG battery cable and SB175 connector specifications. Verify your truck voltage and connector type before ordering to ensure compatibility.
Q: What is the durability and mating cycle life of the DS228886?
A: The DS228886 is rated for up to 10,000 mating cycles, making it suitable for frequent battery disconnect and reconnect operations. The impact-resistant polycarbonate housing (UL94 V-0 flame retardant) provides protection against mechanical damage and heat. Silver-plated copper contacts resist corrosion, extending connector life and maintaining electrical reliability.
Q: Does the DS228886 have mechanical keying to prevent incorrect installation?
A: Yes, the DS228886 features mechanical keying that prevents voltage and color mismatch during connection. This safety feature ensures the connector can only be mated in the correct orientation, preventing polarity reversal or damage to truck electrical systems. The keying mechanism is a critical safety feature for 24V battery systems.
Q: Can the DS228886 be used with different cable gauges?
A: The DS228886 is designed specifically for 1/0 AWG cable. Using cable gauges smaller than 1/0 AWG may result in inadequate contact area and voltage drop. Using larger cable gauges may not fit properly in the connector terminals. Always verify your battery cable gauge matches the 1/0 AWG specification before ordering this connector.
Q: What maintenance is required for the DS228886 connector?
A: Periodically inspect the DS228886 connector terminals for corrosion or loose connections. The silver-plated copper contacts are resistant to oxidation, but moisture and debris can affect electrical conductivity. Ensure the connector seals properly and contacts are clean. Replace the connector if you observe pitting, burn marks, or arcing damage that affects reliability.
