Product Description
Control rod LF PR8046 is a linkage assembly for Lift-Rite manual pallet jack hydraulic control, constructed from SAE 1045 cold drawn steel, with metric M10x1.5 threaded ends. It is designed for direct actuation of the release lever, compatible with standard LCR, LCS, LCM, and LCU Lift-Rite pallet jack models. No cross-reference, supersedes, or interchange part numbers are published. Rod features electroplated corrosion-resistant finish, 0.3125 inch nominal diameter, and 14.00 inch overall length
Compatibility: Fits pallet jacks made by Lift-Rite, model LCR. SKU: LF PR8046
Specifications
Mechanical Specifications
| Mounting | Integrates via split pin and control lever sleeve; adjustable via threaded eyebolt couplers |
| Working Stroke | Provides nominal 4.5 inch actuation travel from neutral to full release position |
Part Numbers
| OEM Part Number | LF PR8046 |
Performance Specifications
| Service Factor | Service factor 1.0 for continuous actuation in non-abrasive environments |
Frequently Asked Questions
Q: What is the LF PR8046 control rod and what does it do in a pallet jack?
A: The LF PR8046 is a linkage assembly and control rod for Lift-Rite manual pallet jack hydraulic control systems. It provides direct mechanical actuation of the release lever to engage the hydraulic pump for raising and lowering loads.
Q: Which Lift-Rite pallet jack models are compatible with the LF PR8046 control rod?
A: The LF PR8046 fits standard Lift-Rite manual pallet jack models including LCR, LCS, LCM, and LCU series. Verify your exact model designation before ordering to confirm compatibility.
Q: What are the key material and dimensional specifications of the LF PR8046?
A: The LF PR8046 is constructed from SAE 1045 cold drawn steel with metric M10x1.5 threaded ends. The nominal shaft diameter is 0.3125 inch and the overall length is 14.00 inches. It features an electroplated corrosion-resistant finish for durability in warehouse environments.
Q: How much actuation travel does the LF PR8046 control rod provide?
A: The LF PR8046 provides a nominal 4.5 inch actuation travel from the neutral position to full release position, allowing the operator to fully engage the hydraulic pump through the entire range of lever motion.
Q: What should I look for when replacing a worn or damaged LF PR8046 control rod?
A: Replace the LF PR8046 if you notice looseness or play in the control lever, if the rod is bent or shows thread damage at the couplers, or if pump engagement feels delayed or incomplete. The rod mounts via split pin and control lever sleeve with adjustable threaded eyebolt couplers. Verify threads and pivot points are not damaged before reinstalling.
Q: Are there any cross-reference or supersedes part numbers for the LF PR8046?
A: No cross-reference, supersedes, or interchange part numbers are published for the LF PR8046. Order using the exact part number LF PR8046 to ensure correct fitment on your Lift-Rite pallet jack.
