Product Description
Crown OEM LED indicator (CR 805835-002) for charger status display on electric lift truck battery chargers; 8 mm panel-mount LED with color-coded state indications, 24VDC input, reverse polarity protection, polycarbonate lens, and continuous duty construction. Designed for direct fitment in Crown charger interface panels.
Specifications
Electrical Specifications
| LED Operating Voltage | 24VDC nominal |
| Connector Type | Pig-tail wire leads, 6-inch, 22 AWG |
Material & Construction
| Lens Material | Polycarbonate, diffused |
| Bezel Material | Anodized aluminum |
| Body Construction | Molded thermoplastic |
Part Numbers & Compatibility
| OEM Part Number | CR 805835-002 |
| Manufacturer Part Number | CR805835-002 |
Performance Specifications
| Duty Cycle | 100% at rated voltage |
Frequently Asked Questions
Q: What is the CR 805835-002 and what does it do?
A: The CR 805835-002 is an OEM LED indicator light for Crown electric lift truck battery chargers. It displays charger status through color-coded state indications (charging, charged, fault, etc.) on the charger interface panel. It is an 8 mm panel-mount LED with 24VDC input.
Q: What are the electrical specifications of the CR 805835-002?
A: The CR 805835-002 operates at 24VDC nominal voltage and includes built-in reverse polarity protection to prevent damage if connected backward. It includes 6-inch, 22 AWG pig-tail wire leads for direct connection to charger control circuits.
Q: What materials are used in the CR 805835-002 construction?
A: The CR 805835-002 features a polycarbonate diffused lens, anodized aluminum bezel, and molded thermoplastic body construction. These materials provide durability, corrosion resistance, and continuous duty performance in warehouse and charging environments.
Q: Is the CR 805835-002 rated for continuous duty operation?
A: Yes, the CR 805835-002 is rated for 100 percent duty cycle continuous operation. It is designed to run uninterrupted during all charger operation phases without thermal shutdown or performance degradation.
Q: Will the CR 805835-002 fit chargers from Toyota, Raymond, or other brands?
A: The CR 805835-002 is an OEM Crown charger part. Compatibility with other charger brands requires matching the 8 mm panel-mount hole diameter, 24VDC input voltage, and wire lead connector type. Always verify specifications before ordering.
