Product Description
Crown CR 813096-001 is an OEM electronic controller module engineered for Crown WP 2300 Series electric pallet trucks. Designed for 24VDC traction and lift system integration, this unit features direct-fit OEM mounting and programmable operation. Compatible with Crown proprietary control systems, the module utilizes a reinforced enclosure and multi-pin power connectors for secure performance in industrial environments.
Specifications
Material & Construction
| Printed Circuit Board | Multi-layer FR4 with conformal coating |
| Terminal Type | Shielded multi-pin power and signal connectors |
Part Numbers
| OEM Part Number | CR 813096-001 |
| Supersedes/Replaces | Supersedes CR 813096-001-R, may require core CR 813096-001-C for renewals |
| Equipment Compatibility | Compatible with Crown WP 2300 Series electric pallet trucks |
Frequently Asked Questions
Q: What equipment does CR 813096-001 electronic controller module fit?
A: CR 813096-001 is an OEM electronic controller module engineered specifically for Crown WP 2300 Series electric pallet trucks. This controller integrates 24VDC traction and lift system functions and features direct-fit OEM mounting compatibility with Crown proprietary control systems.
Q: What are the electrical specifications for CR 813096-001?
A: CR 813096-001 operates at 24VDC and is designed for Crown WP 2300 Series traction and lift system integration. The printed circuit board uses multi-layer FR4 construction with conformal coating for moisture and contamination protection. Terminal connections are shielded to prevent electromagnetic interference in industrial environments.
Q: Is CR 813096-001-R a viable alternative to CR 813096-001?
A: CR 813096-001-R is a rebuilt controller that supersedes the original CR 813096-001 designation. Rebuilt units may require a core exchange. Contact us for current core and rebuild pricing. Both versions provide identical 24VDC functionality for Crown WP 2300 Series trucks.
Q: What maintenance does CR 813096-001 require during service life?
A: CR 813096-001 is sealed in a reinforced enclosure and requires no routine maintenance. Monitor for moisture ingress around multi-pin connectors and visual damage to the enclosure. If the truck exhibits erratic traction or lift response, inspect connectors for corrosion before replacing the controller. Typical service life is 5 to 7 years in standard warehouse conditions.
Q: Can CR 813096-001 be retrofitted to other Crown pallet truck models?
A: No. CR 813096-001 is programmed and mechanically configured exclusively for Crown WP 2300 Series trucks. Attempting cross-model installation will result in non-functional traction and lift systems. Always verify OEM compatibility before ordering replacement controllers.
