Battery Charger for Crown GPW, 40GPW, 2415B1, ET241516B1
CR 109131-001
Battery chargers are model-, voltage-, battery chemistry-, connector-, and sometimes serial-number specific. Using an incompatible charger may result in battery damage, equipment damage, or safety hazards.
Before ordering, confirm:
- Truck make and model
- Serial number
- Battery voltage
- Battery type (lead-acid vs lithium)
- Connector style
If you’re unsure, contact us before purchasing with your equipment details.
Non-Refundable Item: Battery chargers are non-refundable. Please verify compatibility before purchasing.
Couldn't load pickup availability
- Expert support & fitment help
- 30-day returns
- Fast Shipping
Compatibility
|
Make |
|
|---|---|
|
Model |
|
Visit our diagram page for part references to popular models
Product Description
Crown CR 109131-001 battery charger engineered for electric lift trucks; outputs 24VDC, 15A continuous, operates from standard 120VAC input, features aluminum enclosure and forced-air cooling, ring terminal DC connection, and compatibility with Crown electric lift models. Includes verified OEM, manufacturer, and cross-reference part numbers.
Compatibility: Fits pallet jacks made by Crown, model GPW. SKU: CR 109131-001
Specifications
Part Numbers & Compatibility
| Make | Crown |
| Model | GPW Walkie, 40GPW, 2415B1, ET241516B1 |
| Part Number | CR 109131-001 |
| Manufacturer Part Number | CR109131-001 |
| Cross-Reference Part Numbers | Equivalent to CR109131001, 109131001 |
| Compatibility | Fits pallet jacks made by Crown, model GPW |
Electrical Specifications
| Voltage | 24 V |
| Amperage | 15 A |
| Charge Profile | manual timer |
| Battery Chemistry | lead-acid |
| Rated Output Voltage | 24VDC |
| Nominal Output Current | 15A |
Additional Specifications
| Charging Phase Output | Bulk charge phase: up to 24VDC, 15A continuous |
| Power Topology | Switching DC power supply |
| Frequency | 60Hz input |
| Power Connection | Ring terminal DC output connection |
| Casing Material | Aluminum enclosure with forced-air cooling |
Frequently Asked Questions
Q: What are the output specifications for the CR 109131-001 battery charger?
A: The CR 109131-001 outputs 24VDC at 15A continuous in bulk charge phase. Input voltage is 120VAC nominal.
Q: Which electric lift truck models is the CR 109131-001 charger compatible with?
A: The CR 109131-001 is compatible with Crown electric lift truck models GPW, 40GPW, 2415B1, and ET241516B1. Ensure your equipment matches one of these models before ordering.
Q: What are the cross-reference part numbers for the CR 109131-001?
A: The CR 109131-001 is cross-referenced as CR109131-001, 109131001, and CR109131001. These are equivalent part numbers for the same charger unit.
Q: Can the CR 109131-001 charger be used with 230VAC input power?
A: No. The CR 109131-001 requires 120VAC nominal input. For 230VAC applications, the CR 109131-002 is the correct model.
Q: What battery chemistry does the CR 109131-001 charger support?
A: The CR 109131-001 is designed for use with lead-acid batteries.
Q: How do I know if the CR 109131-001 is the right replacement charger for my equipment?
A: Verify your electric lift truck model matches one of the compatible models listed. Check that your battery system uses 24VDC and lead-acid batteries.
