Product Description
Crown CR 062595-002 is a panel-mount rocker switch designed for Crown PE 4000 series electric pallet jacks. This single-pole on-off switch delivers reliable control for lift truck operation with a maximum rating of 2 amperes at 48VDC. Industrial-grade thermoplastic housing and copper alloy contacts provide durability and superior conductivity in demanding warehouse environments.
Specifications
Electrical Specifications
| Rated Operating Voltage | 48VDC maximum |
| Rated Current | 2 amperes |
| Operation Type | SPST single pole, on-off operation |
Physical Specifications
| Switch Body Material | Molded industrial-grade thermoplastic |
| Contact Material | Copper alloy |
| Mounting Configuration | Snap-in panel mount |
Compatibility
| Compatible Makes | Crown |
| Compatible Models | PE 4000, PE4000 |
Part Numbers
| Part Number | CR 062595-002 |
| Alternate Part Number | 062595-002 |
Frequently Asked Questions
Q: What is the CR 062595-002 rocker switch?
A: The CR 062595-002 is a panel-mount rocker switch for Crown PE 4000 series electric pallet jacks. It is a single pole single throw (SPST) on-off switch rated 2A at 48VDC, with industrial-grade thermoplastic housing and copper alloy contacts.
Q: Which Crown models accept the CR 062595-002?
A: The CR 062595-002 is compatible with Crown PE 4000 series electric pallet jacks. The alternate model designation is PE4000. Check your equipment model plate to confirm fitment before ordering.
Q: What are the electrical ratings for the CR 062595-002?
A: The CR 062595-002 is rated 2 amperes maximum current at 48VDC nominal operating voltage. It is a single pole switch for simple on-off control. Do not exceed 2A or operate above 48VDC to avoid contact damage or failure.
Q: What materials are used in the CR 062595-002?
A: The housing is molded industrial-grade thermoplastic for durability in warehouse environments. Contacts are copper alloy to provide reliable conductivity and resistance to oxidation under repeated cycling.
Q: How does the CR 062595-002 differ from the CR 062595-001?
A: The CR 062595-001 is a 10A fan switch at 24VDC with silver contacts and tab terminal. The CR 062595-002 is a 2A rocker switch at 48VDC with copper alloy contacts and snap-in panel mount. They serve different control functions and are not interchangeable.
Q: When should the CR 062595-002 be replaced?
A: Replace the switch if it does not respond to actuation, sticks in the on or off position, shows arcing or burn marks, or causes intermittent loss of control. A failed switch can disable critical lift truck functions and create safety hazards.
