Product Description
Caterpillar CT 301699 Fuse 500A is a high-current, bolt-on power fuse utilized in electric lift truck systems. Rated for 500 amperes continuous, it supersedes CAT 3C0516 and is equivalent to CAT 9712213900, compatible with Caterpillar and Mitsubishi equipment. Features ceramic arc-resistant body and silver-plated copper terminals for panel-mount installation.
Specifications
Electrical
| Fuse Current Rating | 500 amperes (500A) continuous |
| Application Voltage | Up to 80VDC for electric lift trucks |
| Fuse Type | Bolt-on power fuse |
Part Numbers
| Cross-Reference Part Numbers | Supersedes CAT 3C0516, equivalent to CAT 9712213900 |
| OEM Part Number | CAT 3C0516 |
| Equivalent Part Number | CAT 9712213900 |
Performance
| Maximum Breaking Capacity | 50,000 amperes at rated voltage |
Frequently Asked Questions
Q: What amperage is the CT 301699 fuse rated for?
A: The CT 301699 is a high-current bolt-on power fuse rated for 500 amperes (500A) continuous current. It is designed for heavy-duty electric lift truck power distribution systems.
Q: What is the maximum voltage rating for the CT 301699?
A: The CT 301699 is rated for up to 80VDC (80 volts direct current) in electric lift truck applications. This higher voltage rating allows use in advanced electric lift truck systems.
Q: What materials are used in the CT 301699 construction?
A: The CT 301699 features a ceramic arc-resistant body for thermal protection and silver-plated copper terminals for reliable conductivity and corrosion resistance in panel-mount installations.
Q: What equipment does the CT 301699 supersede or cross-reference?
A: The CT 301699 supersedes CAT 3C0516 and is equivalent to CAT 9712213900. It is compatible with Caterpillar and Mitsubishi electric lift truck equipment. Verify your equipment part number before ordering.
Q: What is the fuse type and installation method for the CT 301699?
A: The CT 301699 is a bolt-on power fuse designed for panel-mount installation in electrical distribution systems. The bolt-on design allows secure connection without additional hardware.
