Product Description
OEM control lever for Dayton manual pallet jacks, SKU WW PM-9HB. Functions as the primary actuation component for hydraulic lifting and lowering operations, compatible with Dayton 3KR84 pallet jack hydraulic units. Carbon steel construction with zinc-plated finish. Designed for three-position operation and direct integration with OEM linkage components.
Compatibility: Fits pallet jacks made by Dayton, model 3KR84. SKU: WW PM-9HB
Specifications
Dimensional
| Reference Diagram Number | Item 9 in Dayton hydraulic unit exploded diagram |
Part Numbers
| OEM Part Number | WW PM-9HB |
| Compatible Models | Dayton 3KR84 manual pallet jack hydraulic unit |
Frequently Asked Questions
Q: What is the WW PM-9HB and what does it control?
A: The WW PM-9HB is the OEM control lever for Dayton model 3KR84 manual pallet jacks. It is the primary actuation component that operators use to control hydraulic lifting and lowering operations on the pallet jack.
Q: What material is the WW PM-9HB control lever made from?
A: The WW PM-9HB is constructed from carbon steel with a zinc-plated finish. The zinc plating provides corrosion resistance and durability in warehouse and material handling environments, while carbon steel offers the structural strength needed for repeated actuation.
Q: How many positions does the WW PM-9HB lever have?
A: The WW PM-9HB is designed for three-position operation: lower, neutral, and raise. This three-position design gives operators precise control over hydraulic lift direction and speed.
Q: Is the WW PM-9HB compatible with aftermarket linkage components?
A: The WW PM-9HB is engineered for direct integration with OEM linkage components on Dayton 3KR84 pallet jacks. Use OEM parts to maintain proper mechanical fit and control response. Verify compatibility with any non-OEM components before installation.
Q: When should the WW PM-9HB control lever be replaced?
A: Replace the WW PM-9HB if the lever becomes cracked, bent, does not return to neutral position, or if operations feel loose or unresponsive. A damaged or worn lever compromises operator control and can affect safe lifting operation.
Q: What is the reference location for the WW PM-9HB in Dayton parts diagrams?
A: The WW PM-9HB control lever is Item 9 in the Dayton hydraulic unit exploded diagram for model 3KR84. Use this reference to verify correct part location and assembly position.
