Product Description
Hyster HY 2309160 Fixed Contact for electric lift trucks – OEM copper alloy stationary contact, rated for 175A current and up to 48VDC voltage, with silver plated face and phenolic resin insulator, designed for direct-mount OEM applications. Includes verified dimensions and mechanical specifications.
Specifications
Electrical Specifications
| Short-Term Overcurrent Tolerance | 250A for 5 seconds maximum |
Material & Construction
| Insulator Material | High-strength phenolic resin |
| Contact Hardness | Rockwell B70 minimum |
Part Numbers
| OEM Part Number | HY 2309160 |
| Manufacturer Part Number | HY 2309160 |
Frequently Asked Questions
Q: What are the electrical ratings for HY 2309160 fixed contact?
A: HY 2309160 is rated for 175 amp current capacity at 48VDC maximum voltage. It is designed as a stationary contact for OEM direct-mount applications in Hyster electric lift trucks.
Q: What is the overcurrent tolerance for HY 2309160?
A: HY 2309160 has a short-term overcurrent tolerance of 250 amp for a maximum of 5 seconds. This allows temporary surge handling during truck startup or peak load conditions.
Q: What material is the contact face of HY 2309160?
A: HY 2309160 has a silver-plated contact face that minimizes electrical resistance and resists oxidation. This ensures reliable electrical conductivity throughout the contact service life.
Q: What insulator material does HY 2309160 use and why?
A: HY 2309160 uses high-strength phenolic resin insulator material. Phenolic resin provides excellent electrical insulation, dimensional stability, and durability in industrial truck environments.
Q: What is the contact hardness specification for HY 2309160?
A: HY 2309160 contact hardness is Rockwell B70 minimum, ensuring the contact surface resists wear and deformation during repeated electrical switching cycles.
