Product Description
The CR 076924-20 is a 250-amp, time-delay fuse rated for 130V DC systems used in Crown electric lift trucks and compatible equipment. Constructed with a ceramic body for reliable electrical protection, this fuse measures 3.75 inches in length and 1.062 inches in width. It serves as a direct replacement for Crown 076924-020 and cross-references with Caterpillar 0973047, Hyster 185333, and Barrett 19041-006. Ideal for overcurrent protection in warehouse, loading dock, and material handling applications.
Specifications
Electrical Specifications
| Rated Current | 250 A |
| Voltage Rating | 130 V DC |
| Fuse Type | Time-Delay |
Physical Dimensions
| Length | 3.75 inches |
| Width | 1.062 inches |
Material & Construction
| Fuse Body Material | Ceramic |
Part Numbers
| Crown Part Number | CR 076924-20 |
| Alternate Part Number | 076924-020 |
| Cross-Reference Part Numbers | Caterpillar 0973047; Hyster 185333; Barrett 19041-006 |
Frequently Asked Questions
Q: What are the electrical specifications for the CR 076924-20 fuse?
A: The CR 076924-20 is rated for 250 amps at 130 volts DC. It is a time-delay ceramic fuse with a length of 3.75 inches and width of 1.062 inches. This fuse provides overcurrent protection for Crown electric lift trucks and other material handling equipment requiring 130V protection in this current class.
Q: What equipment is the CR 076924-20 compatible with?
A: The CR 076924-20 is a direct replacement for Crown 076924-020. Cross-reference part numbers include Caterpillar 0973047, Hyster 185333, and Barrett 19041-006, indicating compatibility with Crown, Hyster, Caterpillar, and Barrett electric lift truck models that use 130V, 250A fuse protection.
Q: What material is the CR 076924-20 fuse body made from?
A: The CR 076924-20 features ceramic body construction. Ceramic provides excellent thermal and electrical properties, making it suitable for high-current applications and reliable performance in electric lift truck electrical systems.
Q: How long does a CR 076924-20 fuse typically last?
A: Fuse lifespan depends on system conditions and operational cycles. The CR 076924-20 rated for 250 amps will interrupt when system current exceeds the rated threshold, protecting the lift truck electrical system from damage. Frequent fuse failures may indicate underlying battery, charger, or motor issues requiring diagnosis.
Q: Can I use the CR 076924-20 on a 24V or 36V lift truck?
A: No. The CR 076924-20 is rated specifically for 130V DC systems only. Using an incorrectly rated fuse can result in system damage or failure to provide proper overcurrent protection. Always verify your lift truck voltage rating before ordering. Crown manufactures separate fuse models for 24V, 36V, and other voltage systems.
