Product Description
The 195333 is a 250-amp industrial fuse engineered for electric pallet jacks and lift trucks. Featuring a high thermal plastic body, tin-plated copper terminals, and bolt-on mounting, this direct replacement fuse provides continuous protection up to 32VDC with a 2000-amp breaking capacity. Factory-spec compatible across Hyster, Jungheinrich, and STILL electric material handling equipment platforms.
Specifications
Electrical Specifications
| Fuse Ampere Rating | 250A nominal |
| Voltage Rating | 32VDC maximum operating voltage |
| Breaking Capacity | 2000A |
| Body Material | High thermal plastic |
| Terminal Material | Tin-plated copper |
| Design Type | Bolt-on |
Part Numbers & Compatibility
| Direct Replacement Part Number | HY 195333 |
| Cross-Reference Part Numbers | Hyster 6251903, 343104, 800108978, 350982, 6201903; Jungheinrich 28500510, 28516730; STILL 7916040027 |
| Supersedes Part Numbers | 6251903, 343104 |
| Alternative Part Numbers | HY195333, HYSTER 195333, HYSTER 6251903 |
| Application | Electric pallet jacks and lift trucks |
Frequently Asked Questions
Q: What are the electrical specifications for the 195333 fuse?
A: The 195333 is rated 250A continuous, 32VDC maximum, with a 2000A breaking capacity. It features a high thermal plastic body and tin-plated copper terminals for reliable long-term performance in electric lift truck systems.
Q: What equipment does the 195333 fuse fit?
A: The 195333 is a direct replacement fuse for Hyster, Jungheinrich, and STILL electric pallet jacks and lift trucks. It cross-references to multiple equipment models across all three brands.
Q: What is the mounting design of the 195333?
A: The 195333 uses a bolt-on mounting design with tin-plated copper terminals. This design provides a secure, corrosion-resistant connection and is standard for industrial battery charger and lift truck electrical systems.
Q: How does the 2000A breaking capacity protect equipment?
A: The 2000A breaking capacity means the fuse can safely interrupt fault currents up to 2000A without rupturing or creating arcing hazards. This rating protects both the battery system and load circuits from damage during electrical faults.
Q: Is the 195333 compatible with multiple lift truck brands?
A: Yes. The 195333 is a direct replacement across Hyster, Jungheinrich, and STILL platforms. Always verify voltage and amperage match your specific equipment model before ordering.
