Product Description
Crown CR 805751-006 is a OEM 4 amp ceramic low-peak, CC class time-delay fuse designed for electric lift truck circuit protection in the Crown WP 3000 series. The fuse is rated for applications up to 600 VAC or 300 VDC with a continuous 4 amp maximum current, and features a 1.5 inch length by 0.406 inch diameter cartridge construction.
Compatibility: Fits pallet jacks made by Crown, model WP 3000. Alternate model: WP3000. SKU: CR 805751-006
Specifications
Compatibility
| Equipment Application | Crown Electric Lift Truck WP Series (WP 3000 series) |
Electrical
| Rated Current | 4 A (amperes) continuous |
| Application Voltage | 150 VDC, 300 VDC, 600 VAC maximum |
| Interrupting Rating | Rated for protection of electric lift truck circuit |
| Nominal Operating Frequency | DC or AC circuits up to 600 Hz |
Material
| Body Material | Ceramic tube with plated metal end caps |
Part Numbers
| OEM Part Number | CR 805751-006 |
| Manufacturer Part Number | 805751-006 |
Frequently Asked Questions
Q: What are the voltage and current specifications for the CR 805751-006 fuse?
A: The CR 805751-006 is rated for 4 amperes continuous current and is designed for maximum application voltages up to 150 VDC, 300 VDC, or 600 VAC. This ceramic, low-peak, CC class time-delay fuse is suitable for protecting electric lift truck circuits.
Q: What is the physical construction and dimensions of the CR 805751-006?
A: The CR 805751-006 features a ceramic tube body with plated metal end caps. The cartridge construction measures 1.5 inches in length by 0.406 inches in diameter, making it a standard-sized fuse for lift truck applications.
Q: Which Crown models is the CR 805751-006 compatible with?
A: The CR 805751-006 is designed to fit Crown WP 3000 series electric pallet trucks. Confirm your equipment model matches before ordering.
Q: What does the CC class time-delay rating mean for this fuse?
A: CC class time-delay fuses are designed to tolerate temporary inrush currents while still protecting against sustained overcurrent conditions. This characteristic makes them ideal for motor-driven equipment like electric lift trucks where momentary current spikes occur during startup.
Q: What is the cross-reference part number for the CR 805751-006?
A: The OEM part number is CR 805751-006 and the manufacturer part number is 805751-006. These numbers are equivalent.
