Product Description
Crown CR 076924-007 is a factory-original one-time fuse for 24V electric lift trucks and Wave series, supporting primary circuits up to 200A. Features non-renewable element, fiberglass body, bolt-in mounting, and validated cross-references for replacement.
Specifications
Electrical
| Nominal Voltage | 24VDC system application |
| Rated Continuous Current (Amperage) | 200A (verify application, as alternates 60A and 250A appear in similar series – see content notes) |
Part Numbers
| OEM Part Number | CR 076924-007 |
| Manufacturer Part Number | 076924-007 |
| Cross-Reference Part Numbers | CR076924-7, CR 076924-7, 76924-007, 076924007, SK-43220901SR |
| Equivalent/Interchange Part Numbers | CR076924007, 076924-009 (see notes below – similar part, verify amperage and voltage before interchange) |
| Compatible Equipment Models | Crown electric pallet trucks and Wave series (for 24V systems, verify per equipment manual) |
Frequently Asked Questions
Q: What is the amperage rating and fuse type for CR 076924-007?
A: CR 076924-007 is a factory-original one-time fuse rated at 200 amps for 24V electric lift trucks and Wave series equipment. One-time fuses have a non-renewable element that cannot be reset, so they must be replaced after a single blow.
Q: What is the difference between CR 076924-007 and other Crown fuse models?
A: CR 076924-007 is a one-time non-renewable fuse rated at 200A for 24V circuits, while other Crown models like CR 076924-006 are time delay fuses at 175A and CR 076924-009 is a 250A non-time-delay fuse at 36VDC. Verify your truck voltage and circuit amperage before substitution, as using the wrong fuse creates electrical hazards.
Q: What are the cross-reference part numbers for CR 076924-007?
A: Cross-reference numbers for CR 076924-007 include CR076924-7, CR 076924-7, 76924-007, 076924007, and SK-43220901SR. Verify amperage and voltage match when using cross-references, as similar part numbers may have different ratings.
Q: What materials does CR 076924-007 use?
A: CR 076924-007 features a fiberglass body and bolt-in mounting design. The fiberglass construction provides thermal stability and electrical insulation in the high-current environments of 24V electric lift truck primary circuits.
Q: Can CR 076924-007 be used in place of CR 076924-009?
A: No. CR 076924-007 is rated 200A at 24V, while CR 076924-009 is rated 250A at 36VDC. Using one in place of the other creates electrical hazards. Always verify your truck voltage and circuit amperage specifications before selecting a replacement fuse.
