Product Description
Raymond RA 590-603 is a factory OEM 24VDC horn assembly rated for 110 dB sound output and designed for horizontal panel-mount applications on Raymond electric lift trucks. Includes L&S mounting bracket, impact-resistant thermoplastic cover, and 2-terminal electrical connection. Fits Raymond models 2005+.
Specifications
Electrical
| Operating Voltage | 24VDC nominal |
| Terminal Configuration | 2 terminal connection |
| Maximum Current Draw | 1.3 amps at 24VDC |
| Duty Cycle | Intermittent, rated for up to 60 cycles/hour |
Material & Construction
| Bracket Material | Mild steel, corrosion-protected |
Part Numbers
| OEM Part Number | RA 590-603 |
Performance
| Rated Service Life | Minimum 100,000 actuations at rated input |
Frequently Asked Questions
Q: What voltage does the Raymond horn RA 590-603 require?
A: The RA 590-603 operates at 24VDC nominal. Use this horn only on Raymond electric lift trucks with 24V electrical systems. Do not use on 12VDC equipment.
Q: What sound output rating does the RA 590-603 provide?
A: The RA 590-603 is rated for 110 dB sound output at 24VDC. This high-output specification meets industrial signaling requirements for material handling operations.
Q: What Raymond lift truck models are compatible with the RA 590-603 horn?
A: The RA 590-603 is designed for Raymond electric lift truck models 2005 and later with 24VDC systems and horizontal panel-mount applications. Verify your equipment serial number and mounting configuration before ordering.
Q: What is the maximum current draw and duty cycle for horn RA 590-603?
A: The RA 590-603 draws a maximum of 1.3 amps at 24VDC and is rated for intermittent duty cycle up to 60 cycles per hour. This rating is typical for warehouse warning horns used during backing and turning operations.
Q: What mounting bracket material comes with RA 590-603?
A: The RA 590-603 includes an L and S mounting bracket constructed of mild steel with corrosion protection. The design is suitable for outdoor and warehouse environments. Impact-resistant thermoplastic cover protects the horn assembly.
Q: What is the rated service life and terminal configuration for horn RA 590-603?
A: The RA 590-603 is rated for minimum 100,000 actuations and features a 2-terminal electrical connection. Verify your lift truck harness matches this terminal type and 24VDC voltage for correct installation.
