Product Description
Hyster HY 1361313 Battery Discharge Indicator with integrated hour meter and lockout, OEM part for W40XL and W40XT electric walkie trucks. 24VDC nominal operation, LED bar graph with digital hour tracking, automatic lift interrupt feature, panel mount, flame-retardant polycarbonate housing.
Compatibility: Fits pallet jacks made by Hyster, model W40XL/W40XT. SKU: HY 1361313
Specifications
Electrical Specifications
| Operating Voltage | 24VDC nominal |
| Connector Type | Molex 6-pin, keyed |
| Hour Meter Accuracy | ±1% at 24VDC input |
Material & Construction
| Enclosure Material | Polycarbonate housing, flame retardant, UL94 V-0 |
Part Numbers & Compatibility
| OEM Part Number | HY 1361313 |
| Alternate Part Numbers | HY1361313, 1361313 |
| Compatible Models | Hyster W40XL, Hyster W40XT |
Performance Specifications
| Duty Cycle | Continuous operation, up to 10,000 hours |
| Hour Meter Range | 0 to 99,999 hours, non-resettable |
| Discharge Detection Threshold | Lift lockout activates below 20% remaining battery capacity |
Frequently Asked Questions
Q: What Hyster walkie truck models is the HY 1361313 battery discharge indicator designed for?
A: The HY 1361313 is compatible with Hyster W40XL and W40XT electric walkie trucks. This is an integrated battery monitoring and lift control module specific to these models.
Q: What is the operating voltage for the HY 1361313?
A: The HY 1361313 operates at 24VDC nominal input. It is designed to integrate with standard 24V electrical systems on Hyster walkie pallet jacks.
Q: What functions does the HY 1361313 provide?
A: The HY 1361313 integrates a battery discharge indicator with LED bar graph display, digital hour meter tracking, and automatic lift interrupt lockout. Hour meter accuracy is plus or minus 1 percent at 24VDC input. When battery capacity drops to minimum threshold, the lift circuit is automatically disabled to prevent stranded equipment.
Q: What is the connector type for the HY 1361313?
A: The HY 1361313 uses a Molex 6-pin keyed connector. Verify connector compatibility with your truck harness before installation. The keyed design ensures correct polarity and orientation.
Q: What housing material is the HY 1361313 enclosure?
A: The HY 1361313 is housed in flame-retardant polycarbonate (UL94 V-0 rating) for panel mounting. This material resists impact, moisture, and meets industrial electrical safety standards for material handling equipment.
Q: Is the HY 1361313 a direct OEM replacement?
A: Yes. The HY 1361313 (alternate part numbers HY1361313, 1361313) is an OEM Hyster replacement module designed as a direct fit for W40XL and W40XT equipment. It integrates with factory wiring and mounting brackets.
