Product Description
Handle control assembly for Hyster electric pallet jacks and walkie lift trucks, part number HY 2308319, designed as a direct replacement for W40XL and W40XT models. Features dual microswitch speed control with reinforced thermoplastic construction and stainless steel pivot for durability in warehouse environments. Operates at 24VDC nominal control voltage with a direct replacement harness connector. Essential control component for lift speed and directional operator interface.
Specifications
Dimensional
| Mounting Hole Pattern | Dual bolt, 1.75 inch center-to-center |
Electrical
| Control Voltage | 24VDC nominal |
| Connector Type | OEM harness plug-in, 6-pin layout |
| Current Rating | Rated for signal-level switching up to 0.5A |
Material & Construction
| Handle Construction | Reinforced thermoplastic with stainless steel pivot |
Part Numbers & Compatibility
| OEM Part Number | HY 2308319 |
| Manufacturer Part Number | 2308319 |
| Cross-Reference Part Numbers | 1673882 (aftermarket equivalent) |
| Compatible Equipment Models | Hyster W40XL, Hyster W40XT electric pallet jack |
Performance
| Duty Cycle | Continuous operation, rated for 120 actuation cycles/hour |
| Service Life | Rated for 100,000 actuation cycles minimum |
Frequently Asked Questions
Q: What is the HY 2308319 and what equipment does it fit?
A: The HY 2308319 is a handle control assembly for Hyster electric pallet jacks and walkie lift trucks, designed for direct replacement on W40XL and W40XT models. It provides operator interface for lift speed control and directional commands.
Q: What are the electrical specifications of the HY 2308319?
A: The HY 2308319 operates at 24VDC nominal control voltage. It features dual microswitch speed control for variable lift and lower speeds. The connector is a 6-pin OEM harness plug-in type designed for direct connection to Hyster lift control systems.
Q: What material is the HY 2308319 constructed from?
A: The HY 2308319 handle assembly is manufactured from high-impact thermoplastic, providing durability against drops, impacts, and vibration in warehouse environments. The material resists cracking and maintains tactile grip surfaces through extended use cycles.
Q: What is the cross-reference part number for the HY 2308319?
A: The HY 2308319 has cross-reference part number 1673882 available as an aftermarket equivalent. Confirm connector compatibility and microswitch rating before substituting alternative part numbers.
Q: What symptoms indicate the HY 2308319 requires replacement?
A: Replace the assembly if lift or lower functions become unresponsive, speed control is erratic or stuck at one speed, or if the handle is physically cracked or broken. Test the 24VDC connection and verify signal output at the 6-pin connector before ordering replacement.
Q: How does the dual microswitch speed control work on the HY 2308319?
A: The dual microswitch design allows variable speed control. The primary switch engages full lift or lower speed, while the secondary switch reduces speed for precision positioning. This gives operators smooth acceleration control and gentle load handling at low speeds for sensitive materials or stacking operations.
