Product Description
The HY 2309185 is a 90-degree SAE x JIC hydraulic fitting elbow designed for Hyster electric lift trucks and pallet jacks. This direct replacement component provides a robust mechanical connection for hydraulic lines in demanding warehouse and dock applications. Engineered for reliable performance in Hyster W40Z and W45Z series equipment, it ensures consistent hydraulic system functionality and load security during transport and lifting operations.
Specifications
Part Numbers
| Part Number | HY 2309185 |
| Manufacturer Part Number | 16559 |
Specifications
| Connection Type | 90-Degree Elbow, SAE x JIC 37-Degree Cone |
| Compatible Equipment | Hyster W40Z, W45Z(B218) |
Frequently Asked Questions
Q: What equipment does the HY 2309185 fit?
A: The HY 2309185 is a 90-degree SAE x JIC hydraulic fitting elbow designed for Hyster electric pallet jacks, specifically Hyster W40Z and W45Z(B218) models.
Q: What type of hydraulic connection is the HY 2309185?
A: This is a 90-degree elbow fitting with SAE connection on one end and JIC 37-degree cone connection on the other. Verify your hydraulic system connection types before ordering.
Q: What are the part number references for the HY 2309185?
A: The primary part number is HY 2309185, with manufacturer part number 16559. Cross-check documentation for your equipment to confirm this is the correct replacement.
Q: What materials is the HY 2309185 constructed from?
A: Hydraulic fittings are typically manufactured from steel or aluminum with corrosion-resistant coatings. Confirm material specifications with technical documentation if compatibility with specific hydraulic fluids is critical.
Q: Can the HY 2309185 be used in other Hyster models?
A: This fitting is specified for Hyster W40Z and W45Z(B218) models. Cross-reference your equipment serial range and hydraulic schematic before ordering for other Hyster equipment.
