Product Description
Exit roller assembly for Lift-Rite and Big Joe L-50M series low-profile manual pallet jacks. This component mounts at the rear fork frame position and is compatible with L-50M, L-50M-4WAY, L-50MU, and L-50MU-4WAY models. Supports frame widths from 20.5 to 33 inches and fork lengths from 36 to 48 inches. Suitable for both 2-inch and 1.75-inch low-profile configurations, this exit roller ensures smooth load handling and reliable operation across a range of manual pallet jack applications.
Specifications
Part Information
| Part Number | 10220-M |
| Cross-Reference Part Numbers | 10220, LF10220-M |
| Compatible Models | L-50M, L-50M-4WAY, L-50MU, L-50MU-4WAY, L-50, L91 |
| Replaces Part Numbers | 10220 |
Material & Specifications
| Hardness | Approximately 85 Shore D (industrial polymer roller standard) |
| Frame Width Support | 20.5 to 33 inches |
| Fork Length Support | 36 to 48 inches |
| Mounting Position | Rear fork frame with 10219-M pivot axle |
| Frame Configuration Compatibility | 2-inch and 1.75-inch low-profile |
Frequently Asked Questions
Q: Which manual pallet jack models use the LF 10220-M exit roller?
A: The LF 10220-M fits Lift-Rite and Big Joe L-50M, L-50M-4WAY, L-50MU, and L-50MU-4WAY low-profile pallet jacks. It supports frame widths from 20.5 to 33 inches and fork lengths from 36 to 48 inches.
Q: What pivot axle does the LF 10220-M require?
A: The LF 10220-M mounts with the LF 10219-M pivot axle at the rear fork frame position. Both components must be replaced together for proper assembly and safe operation.
Q: Is the LF 10220-M compatible with both 2 inch and 1.75 inch low-profile frame configurations?
A: Yes. The LF 10220-M is designed for both 2 inch and 1.75 inch low-profile frame configurations used in Lift-Rite and Big Joe L-50M series jacks. Check your frame height specification before ordering.
Q: What equivalent part numbers can replace the LF 10220-M?
A: The LF 10220-M is equivalent to 10220, 10220-M, and other cross-references. These numbers are interchangeable when the frame model and width match your equipment.
Q: What hardness specification does the LF 10220-M roller meet?
A: The LF 10220-M is estimated to have approximately 85 Shore D hardness, which is standard for industrial pallet jack rollers. This hardness supports repeated load cycles without deformation or cracking.
