Product Description
The Raymond RA 632-069-004-A is a factory-spec load wheel assembly designed for Raymond electric pallet trucks. Featuring a durable polyurethane tread with 95A durometer hardness, this 3.25-inch diameter wheel delivers reliable floor protection and load stability. Precision-engineered with four sealed 6205-2RS ball bearings for long service life in industrial warehouse environments, this wheel assembly ensures consistent performance across Raymond 8300, 8400, and 8500 series equipment.
Specifications
Material
| Tread Compound | Polyurethane compound, Shore A 95 durometer |
| Core Material | Precision-cast steel core |
| Surface Finish | Machined wheel faces, as supplied |
| Diameter | 3.25 inches |
| Width | 5.50 inches |
| Ball Bearings | Four 6205-2RS sealed ball bearings |
Part Numbers
| Part Number | RA 632-069-004-A |
| Cross-Reference Part Numbers | Supersedes RA 632-069, equivalent to RA 632-069-A, interchangeable with RA 632-069-003 and RA 632-069-107 |
| Compatible Models | Raymond 8300, 8400, 8500 electric pallet trucks |
Frequently Asked Questions
Q: What equipment does the RA 632-069-004-A load wheel fit?
A: The RA 632-069-004-A is a direct OEM replacement load wheel for Raymond 8300, 8400, and 8500 electric pallet trucks. This wheel assembly is designed for high-capacity electric lift equipment and provides compatibility across this model range.
Q: What are the physical dimensions and bearing specifications of the RA 632-069-004-A?
A: The RA 632-069-004-A features a 3.25-inch diameter with a 5.50-inch tread width. The wheel is equipped with four 6205-2RS ball bearings, which provide sealed protection against contamination and extended service life in industrial environments.
Q: What is the tread material and durometer hardness of this load wheel?
A: The RA 632-069-004-A uses a polyurethane tread with a 95A durometer hardness rating. This provides a good balance of load capacity, floor protection, and wear resistance for general material handling applications.
Q: What are the cross-reference and superseding part numbers for the RA 632-069-004-A?
A: The RA 632-069-004-A supersedes the RA 632-069 and is equivalent to RA 632-069-A. It is interchangeable with RA 632-069-003 and RA 632-069-107 for direct replacement purposes.
Q: How long will the polyurethane tread on this wheel last in typical use?
A: Polyurethane load wheel lifespan depends on load cycles, floor conditions, and maintenance. At 95A durometer, the RA 632-069-004-A provides moderate wear resistance. Wheels typically last 1 to 3 years under normal warehouse duty. Inspect for tread wear, flat spots, or bearing noise as replacement indicators.
