Lock Washer for Magnum/Handjak 5000
MG 519
Guaranteed Fit. If it doesn’t fit equipment that matches the listing on this page, we’ll exchange or refund it: no restocking fee, return shipping on us. How it works
Not sure it fits? Check it with us before you buy. Once we confirm the fit in writing, it’s guaranteed for your machine.
Couldn't load pickup availability
- Expert support & fitment help
- 30-day returns
- Fast Shipping
Compatibility
|
Make |
|
|---|---|
|
Model |
|
Visit our diagram page for part references to popular models
Product Description
Lock washer MG 519 is a carbon steel, spring-profile locking washer engineered for Magnum manual pallet jack frame assemblies. Designed to maintain clamping tension in high-vibration applications, it features a helical profile, nominal 0.625 inch bore, and meets ANSI B18.21.1 standards.
Compatibility: Fits pallet jacks made by Magnum, model 5000. SKU: MG 519
Specifications
Material
| Hardness | Rockwell C35 nominal |
Part Numbers
| Manufacturer Part Number | MG 519 |
| OEM Part Number | MG 519 |
| Compatible Equipment Model | Magnum 5000 Frame manual pallet jack |
Frequently Asked Questions
Q: What is the material and design of the MG 519?
A: The MG 519 is a carbon steel spring-profile locking washer with a helical profile design. It is engineered to maintain clamping tension in high-vibration applications found on manual pallet jack frames.
Q: What equipment does the MG 519 fit?
A: The MG 519 is compatible with Magnum Model 5000 frame manual pallet jacks and fits applications requiring a 0.625 inch bore locking washer.
Q: What is the bore size of the MG 519?
A: The MG 519 has a nominal 0.625 inch bore size, designed to fit standard fasteners used in Magnum Model 5000 frame assemblies.
Q: What standards does the MG 519 meet?
A: The MG 519 conforms to ANSI B18.21.1 standards for spring lock washers, ensuring consistent dimensions and performance across applications.
Q: What is the hardness specification for the MG 519?
A: The MG 519 has a nominal Rockwell C35 hardness, providing the right balance of strength and spring tension for vibration resistance in frame assemblies.
