Product Description
Micro-switch for electric lift truck applications with SPST normally open contacts, roller lever, 33mm length x 15.9mm width body, 200gf operation force, 0.1A at 48VDC/125-250VAC rating, IP67 waterproof enclosure. No verified cross-reference part numbers.
Specifications
Electrical
| Voltage Rating | 0.1A at 48VDC, 0.1A at 125/250VAC |
| Current Rating | Up to 10A at 125/250VAC, 0.5A at 122VDC, 0.25A at 250VDC |
| Electrical Life | 20,000 to 100,000 cycles |
Material & Construction
| Protection Grade | IP67 rated (waterproof and dustproof) |
| Case Material | Plastic with electroplating finish |
Frequently Asked Questions
Q: What is the 175806811 micro-switch rated for?
A: SKU 175806811 is a micro-switch for electric lift truck applications with SPST normally open contacts. It is rated for 0.1A at 48VDC and 0.1A at 125-250VAC, with a maximum current capacity up to 10A at 125-250VAC depending on voltage. Verify your equipment voltage before ordering.
Q: What does IP67 protection mean for the 175806811?
A: IP67 means the switch is waterproof and dustproof, rated for temporary immersion up to 1 meter. This rating makes the 175806811 suitable for wet environments and cold storage areas common in material handling operations.
Q: What is the body size of the 175806811 micro-switch?
A: The 175806811 has a plastic body with electroplating finish measuring 33mm length by 15.9mm width. It features a roller lever activation mechanism with 200gf operation force. Verify these dimensions fit your equipment mounting location.
Q: How many electrical cycles does the 175806811 micro-switch endure?
A: The 175806811 is rated for 20,000 to 100,000 electrical cycles depending on load and switching frequency. Life expectancy varies by duty cycle. Heavy-use applications with frequent switching may require replacement sooner than light-duty installations.
Q: Can the 175806811 replace a micro-switch with different voltage ratings?
A: No. The 175806811 is specifically rated for 48VDC and 125-250VAC circuits. Using it on equipment with different voltage specifications risks switch failure, electrical damage, or safety hazards. Verify your equipment voltage matches before installation.
Q: Is there a cross-reference part number for the 175806811 micro-switch?
A: The 175806811 currently has no verified cross-reference part numbers. Contact us with your equipment brand and model, and we can confirm compatibility or identify equivalent alternatives if the 175806811 is not in stock.
