Product Description
Industrial micro-switch designed for electric lift truck control systems. Features snap-action SPDT contacts rated at 10A/250VAC, with thermoplastic housing and stainless steel plunger actuator. OEM part number 29000465-00, supersedes NI29000465-000-ORG, and equivalent to Z-15GW22-B. Panel mount with screw terminal connections. Specified for long life in electric forklift motion and safety control circuits.
Specifications
Dimensional
| Mounting Hole Pattern | 0.875 inch center-to-center |
Electrical
| Contact Rating | 10A at 250VAC |
Material & Construction
| Actuator Material | Stainless steel |
Part Numbers
| Manufacturer Part Number | 29000465-00 |
| OEM Part Number | NI29000465-000-ORG |
| Supersedes/Replaces | Supersedes Nissan OEM 29000465-00 |
| Equivalent Part Number | Z-15GW22-B |
Performance
| Operating Cycles | Minimum 1,000,000 mechanical cycles |
Frequently Asked Questions
Q: What is the electrical rating for micro-switch 29000465-00?
A: Micro-switch 29000465-00 is rated at 10A at 250VAC with snap-action SPDT (single-pole, double-throw) contacts. This rating applies to electric lift truck control and safety circuits under normal operating conditions.
Q: Which electric lift trucks use micro-switch 29000465-00?
A: This OEM part 29000465-00 is used in electric forklift and lift truck motion control systems from Nissan, Toyota, Caterpillar, Hyster, Yale, and other manufacturers. Verify your equipment model and application before ordering, as mounting configuration and terminal types vary.
Q: What are the physical specifications of 29000465-00?
A: This switch features a thermoplastic housing with stainless steel plunger actuator, panel mount configuration, and 0.875 inch center-to-center mounting hole pattern. Screw terminal connections accommodate standard wire gauges for industrial circuits.
Q: What cross-reference and equivalent part numbers match 29000465-00?
A: OEM part number NI29000465-000-ORG and equivalent aftermarket part Z-15GW22-B are functionally equivalent to 29000465-00. Verify electrical ratings, mounting dimensions, and terminal type match your equipment circuit before substitution.
Q: How long does a micro-switch like 29000465-00 typically last?
A: Industrial micro-switches rated for long life typically endure 1 to 3 million mechanical cycles in motion control and safety circuits. Actual lifespan depends on operating frequency, electrical load, environmental conditions, and proper contact alignment.
Q: What should I check when replacing micro-switch 29000465-00?
A: Verify the new switch has identical electrical ratings (10A/250VAC), matching contact type (SPDT), correct mounting hole spacing (0.875 inch), and compatible terminal configuration for your circuit wiring. Confirm the replacement part number matches OEM specification or approved equivalent.
