Product Description
Micro-switch for electric lift trucks, OEM part number 3025474, compatible with select models and interchangeable with Omron Z-15GW22-B and Hyster HY3025474-ORG. Features SPDT contact, roller lever actuator, 15A/250VAC rating, panel mount configuration, and molded plastic housing.
Specifications
Electrical
| Rated Voltage | 250VAC maximum |
| Rated Current | 15A at 250VAC |
Part Numbers
| OEM Part Number | 3025474 |
| Equivalent Part Number | HY3025474-ORG |
| Cross-Reference Part Numbers | P/N Z-15GW22-B (Omron), HY3025474-ORG (Hyster) |
Frequently Asked Questions
Q: What is micro-switch 3025474 used for in electric lift trucks?
A: Micro-switch 3025474 is an electrical control component that activates or deactivates circuits based on mechanical position or load detection. It is commonly used in tilt mechanisms, lift height limiters, and load sensing systems on electric forklifts and pallet jacks.
Q: What are the electrical specifications of micro-switch 3025474?
A: Micro-switch 3025474 has a rated voltage of 250VAC maximum, rated current of 15A at 250VAC, SPDT contact configuration (single pole double throw), roller lever actuator, and panel mount configuration with molded plastic housing.
Q: Is micro-switch 3025474 compatible with other brands?
A: Micro-switch 3025474 is interchangeable with Omron Z-15GW22-B and Hyster HY3025474-ORG equivalents. Cross-reference your equipment OEM part number before ordering to ensure electrical compatibility and mechanical fitment.
Q: Which electric lift truck models use micro-switch 3025474?
A: Micro-switch 3025474 is compatible with select Hyster, Yale, Crown, Toyota, and Raymond electric lift trucks. Confirm your equipment make, model, and serial number range to verify this switch is the correct replacement.
Q: What symptoms indicate a failed micro-switch 3025474?
A: Signs of failure include non-responsive circuit functions, inability to activate or deactivate lift mechanisms, intermittent control behavior, or audible clicking when actuator is depressed. Replace the switch if functionality does not restore after connector inspection.
