Micro-Switch for Rotary Lift, Challenger Lift, Forward Lift, SPX
800134537
Guaranteed Fit. If it doesn’t fit equipment that matches the listing on this page, we’ll exchange or refund it: no restocking fee, return shipping on us. How it works
Not sure it fits? Check it with us before you buy. Once we confirm the fit in writing, it’s guaranteed for your machine.
Couldn't load pickup availability
- Expert support & fitment help
- 30-day returns
- Fast Shipping
Compatibility
|
Make |
|
|---|---|
|
Model |
|
Visit our diagram page for part references to popular models
Product Description
The 800134537 micro-switch is a snap-action, normally open switch rated for 270 VAC at 25A, designed for electric lift truck hydraulic motor cutoff applications. Functionally compatible with Rotary, Challenger, SPX, and Direct Lift models; it possesses cross-reference part numbers including Rotary N413-1, SPX 4611-AA, BH-7004-36, and others. Features plastic push-button actuator, two spade terminals, and mounts via diagonal corner holes within standard switch housings.
Specifications
Electrical
| Rated Voltage | 270 VAC maximum |
| Rated Current | 25 A at 270 VAC |
| Contact Configuration | 2 male spade terminals |
Functionality & Application
| Functionality | Snap-action, normally open switch |
| Application | Electric lift truck hydraulic motor cutoff |
| Actuator Type | Plastic push-button actuator |
Material & Construction
| Body Material | Molded plastic housing |
| Mounting Type | Diagonal corner holes within standard switch housings |
Part Numbers
| Part Number | 800134537 |
| Cross-Reference Part Numbers | Rotary Lift N413-1, Challenger Lift 2001917, Forward Lift 992117, SPX 4611-AA, BH-7004-36, P1483, BH-7538-54, 4611-AA |
| Supersedes Part Numbers | P1483, BH-7004-36, BH-7538-54 |
Frequently Asked Questions
Q: What are the electrical ratings for the 800134537 micro-switch?
A: The 800134537 is rated for 270 VAC maximum voltage and 25A maximum current at 270 VAC. It is a snap-action, normally open (NO) switch designed for hydraulic motor cutoff circuits in electric lift trucks.
Q: Which lift truck brands does the 800134537 work with?
A: The 800134537 is functionally compatible with Rotary Lift (reference N413-1), Challenger Lift (2001917), Forward Lift (992117), SPX (4611-AA), and Direct Lift models. Cross-reference part numbers include BH-7004-36, P1483, BH-7538-54, and 4611-AA.
Q: What is the physical actuator type on the 800134537?
A: The 800134537 features a plastic push-button actuator for manual activation. It mounts via two diagonal corner holes into standard switch housings and connects via two spade terminals.
Q: Can I use the 800134537 as a direct replacement for part P1483 or BH-7004-36?
A: Yes. The 800134537 supersedes parts P1483, BH-7004-36, and BH-7538-54. Mounting configuration and terminal type are compatible with standard hydraulic motor cutoff circuits on electric lift trucks using these original part numbers.
Q: What happens when the 800134537 activates in a hydraulic motor circuit?
A: The 800134537 is a normally open switch that closes its contacts when actuated, completing the circuit to trigger a cutoff valve or relay. This stops hydraulic motor operation. The snap-action mechanism ensures reliable, positive engagement.
Q: How long does an 800134537 micro-switch typically last?
A: Industrial snap-action micro-switches like the 800134537 typically last 5 to 10 years in standard duty service, or longer in lower-cycle applications. Life depends on electrical load, switching frequency, and environmental exposure. Contact us if you see slow engagement or intermittent operation.
