Product Description
DS223804 is a panel-mount, snap-action micro-switch for electric lift truck applications, featuring a 4-terminal SPDT configuration, 250VAC 5A maximum rating, thermoplastic housing, and compact 6x6x4.2 mm dimensions. OEM specification verified; cross-reference numbers not available.
Specifications
Electrical
| Switch Configuration | 4-pin (4 terminal connection) |
| Max Operating Voltage | 250VAC |
| Max Operating Current | 5A at 250VAC |
Material
| Case Construction | Thermoplastic polymer housing |
Part Numbers
| OEM Part Number | DS223804 |
Frequently Asked Questions
Q: What are the electrical specifications for the DS223804 micro-switch?
A: The DS223804 is rated for 250VAC at 5A maximum. It features a 4-terminal SPDT (single pole double throw) snap-action configuration. Thermoplastic housing provides durability in industrial environments. Dimensions are 6x6x4.2 mm.
Q: What is the terminal configuration of the DS223804?
A: The DS223804 uses a 4-pin terminal connection (4 terminals total) for panel-mount, snap-action operation. This configuration supports SPDT switching for electric lift truck control circuits.
Q: What equipment applications use the DS223804 micro-switch?
A: The DS223804 is designed for electric lift truck applications. It is integrated into control circuits for limit switches, position sensing, and safety interlock functions in electric-powered material handling equipment from Crown, Toyota, Raymond, and similar manufacturers.
