Product Description
MO 100/210-A steer wheel assembly manufactured by Mobile features a 6.00 inch diameter carbon steel wheel with dual sealed ball bearings sized for 3/4 inch axle compatibility. The wheel is constructed from ASTM A36 steel, protected with black oxide coating, and rated for 1,200 lbs per wheel at a standard 24 inch load center. Bearing specification follows single-row deep groove ball type, utilizing nitrile rubber seals and SAE 52100 steel components. Dimensional accuracy includes 2.00 inch hub wi
Compatibility: Fits pallet jacks made by Mobile, model ML50, ML55 (Older). SKU: MO 100/210-A
Specifications
Material
| Bearing Material | SAE 52100 Chrome Steel (hardened) |
| Wheel Hardness | Rockwell C45 minimum |
Part Numbers
| Manufacturer Part Number | MO 100/210-A |
| Compatible Models | Mobile ML50, ML55 (Pre-2000 series pallet jack platforms) |
Frequently Asked Questions
Q: What are the wheel specifications for the MO 100/210-A steer wheel assembly?
A: The MO 100/210-A features a 6.00 inch diameter wheel constructed from ASTM A36 carbon steel with black oxide coating. The wheel has a 2.00 inch hub width and is rated for 1,200 lbs per wheel at a 24 inch load center. Bearing configuration includes single-row deep groove ball type with SAE 52100 steel components and nitrile rubber seals. Axle compatibility is 3/4 inch.
Q: Which pallet jack models does the MO 100/210-A fit?
A: The MO 100/210-A is compatible with Mobile ML50 and ML55 manual pallet jack platforms, specifically the older design and pre-2000 series models. Verify your equipment serial range and model designation before ordering.
Q: What cross-reference part numbers are equivalent to MO 100/210-A?
A: The MO 100/210-A is equivalent to OEM part number MO100/210-1-A. Cross-reference equivalents include 100/210-1-A, Mobile 100/210-1-A, and ML100/210-1-A. These designations reference the same assembly.
Q: Why is the MO 100/210-A steer wheel suitable for manual pallet jack service?
A: The dual sealed ball bearings with nitrile rubber seals provide protection against contamination and moisture in typical material handling environments. The black oxide coating resists corrosion and extends service life. SAE 52100 bearing steel delivers durability under repetitive load cycling common in warehouse and manufacturing operations.
Q: What is the rated load capacity for the MO 100/210-A wheel?
A: The MO 100/210-A wheel is rated for 1,200 lbs per wheel at a standard 24 inch load center. This rating assumes proper load distribution across all wheels and compliance with pallet jack design specifications.
