Product Description
Polyurethane press-on drive tire, SKU SU 9X5X5-SF-P, for electric lift trucks and warehouse forklifts. 9 inch OD x 5 inch width x 5 inch ID, 3020 lbs capacity at 6 mph, SPS Soft-Ride non-marking compound, 85A durometer hardness, engineered for chemical resistance, smooth concrete floors, and improved ride comfort.
Specifications: 9.000 inch diameter x 5.000 inch width (9.000" x 5.000" | 9 x 5 wheel | 9 x 5-0/0 | 228.60mm x 127.00mm)
Specifications
Material & Construction
| Hardness | 85 Durometer (Shore A) |
Part Numbers
| OEM Part Number | SU 9X5X5-SF-P |
Wheel Specifications
| Outside Diameter (in) | 9.000 |
| Width (in) | 5.000 |
| Outside Diameter (mm) | 228.60 |
| Width (mm) | 127.00 |
| Drive Tire Profile | Smooth Flat |
| Material | Polyurethane |
Frequently Asked Questions
Q: What are the rated specifications for this polyurethane drive tire?
A: The SU 9X5X5-SF-P is 9.000 inches outside diameter by 5.000 inches width with a 3020 lbs maximum load capacity at 6 mph. The material is polyurethane at 85A durometer hardness using SPS Soft-Ride non-marking compound, measuring 228.60mm by 127.00mm in metric dimensions.
Q: Is the SU 9X5X5-SF-P equivalent to any other branded tires?
A: The SU 9X5X5-SF-P is a universal press-on tire that fits most electric lift trucks and warehouse forklifts with 9x5 wheel configurations. Compare dimensional specifications and bore size with your equipment manual to confirm compatibility. Some manufacturers use equivalent 9x5 tires under different SKUs but the same 228.60 x 127.00mm dimensions will interchange.
Q: What does non-marking compound mean and why does it matter?
A: Non-marking compound means the tire will not leave black scuff marks or deposits on clean warehouse floors. The SPS Soft-Ride formulation is specifically engineered for food processing, pharmaceuticals, and electronics facilities where floor marking is unacceptable. The compound also provides excellent grip on smooth concrete.
Q: How does this tire perform in high-moisture or wet environments?
A: This polyurethane tire performs well in wet conditions and maintains grip on moisture-covered floors. However, standing water and persistent high humidity can slightly swell the elastomer over extended periods. Drain floors properly and store tires in a dry area. Do not operate continuously in flooded conditions.
Q: What maintenance is required for this press-on tire?
A: Inspect the tire monthly for cracks, chunks, or separation from the hub. Clean with mild soap and water to remove dust and debris. Do not use harsh solvents or high-pressure washers as these damage the surface. Check the hub mounting for looseness and re-press if needed. Rotate tires between drive wheels every 6 months for even wear.
Q: When should I replace this tire?
A: Replace the tire when the smooth tread surface wears flat and becomes glossy, when chunks or deep cracks appear, or when you notice vibration or uneven wear patterns. Typical lifespan is 2 to 4 years depending on floor type and load. Do not continue operating with damaged tires as this can cause hub damage and equipment failure.
