Product Description
Prime Mover brake interlock switch, sealed design, manufacturer part number PR 20323-00. Compatible with WRX30 and CSX series electric pallet trucks. Electrical rating: 24VDC, 5A, SPDT contacts, stainless steel actuator. Panel mount, Faston blade terminals, designed for industrial lift truck applications.
Specifications
Electrical
| Switch Voltage Rating | 24VDC nominal (max 48VDC) |
| Current Rating | 5A at 24VDC resistive |
| Dielectric Strength | 1000V RMS at 60 Hz for 1 minute |
Material
| Actuator Material | Stainless steel, sealed |
Part Numbers
| Manufacturer Part Number | PR 20323-00 |
| OEM Part Number | 20323-00 |
| Compatible Models | BT Prime Mover WRX30, CSX10, CSX20, CSX30, CSX40 series electric pallet trucks |
Performance
| Mechanical Life | 1,000,000 cycles at rated load |
| Service Factor | 1.0 continuous |
Frequently Asked Questions
Q: What BT Prime Mover pallet truck models is the PR 20323-00 brake interlock switch compatible with?
A: The PR 20323-00 is designed for BT Prime Mover WRX30 and CSX series electric pallet trucks, including CSX10, CSX20, CSX30, and CSX40 models. Verify your equipment model and serial number before ordering to confirm compatibility.
Q: What are the electrical specifications for the PR 20323-00 switch?
A: The PR 20323-00 is rated 24VDC nominal with a maximum of 48VDC. Current rating is 5 amps at 24VDC resistive load. Contact configuration is SPDT (single-pole double-throw). Faston blade terminals are provided for panel mount installation. Do not exceed these electrical ratings.
Q: What is the function of the brake interlock switch in an electric pallet truck?
A: The brake interlock switch prevents truck operation when the brake is not fully engaged. It is a safety device that ensures the truck remains stationary during loading, unloading, or when the operator releases the controls. A failed interlock switch can create a safety hazard.
Q: What material is the PR 20323-00 actuator made from?
A: The PR 20323-00 features a stainless steel actuator with sealed design. Stainless steel resists corrosion and mechanical wear, extending switch life in industrial environments. The sealed design protects internal contacts from dirt and moisture.
Q: How can I tell if the PR 20323-00 brake interlock switch has failed?
A: Symptoms of a failed brake interlock switch include truck operation without brake engagement, inconsistent brake function, or loss of driving power. If the truck does not respond to brake control input or operates unexpectedly, test the interlock switch. A multimeter can verify electrical continuity.
Q: Is the PR 20323-00 a sealed or open design?
A: The PR 20323-00 uses a sealed design, meaning the internal contacts are protected from environmental contamination, dust, and moisture. This sealed construction increases reliability in warehouse and material handling environments.
