Product Description
Raymond RA 312677-KIT handle stem assembly is a machined steel component designed for electric pallet truck tiller arm mounting. Features a precision-ground, induction-hardened shaft with keyway, compatible with Raymond 102T-F45L models. Supersedes RA312677-000 with improved surface hardness and fit for self-aligning bearings.
Specifications
Material & Construction
| Material Specification | Machined steel grade SAE 1045 |
| Surface Finish | Precision ground and polished, Ra = 1.6 µm |
| Hardening Treatment | Induction-hardened shaft |
Mechanical Specifications
| Thread Specification | M16 x 1.5 internal |
| Keyway Design | Precision-ground for secure mounting |
Part Numbers
| Direct Replacement Part Number | RA 312677-KIT |
| Cross-Reference Part Numbers | RA312677-000 |
| Supersedes/Replaces Part Numbers | RA312677-000 |
| Compatible Models | Raymond 102T-F45L |
Performance Specifications
| Service Factor | 1.15 continuous operation |
| Application | Electric pallet truck tiller arm steering assembly |
Frequently Asked Questions
Q: What material is the RA 312677-KIT handle stem made from?
A: RA 312677-KIT is machined from SAE 1045 steel grade with induction-hardened shaft treatment. The precision-ground keyway design provides secure mounting compatibility with self-aligning bearings on the tiller arm assembly.
Q: Does RA 312677-KIT have a cross-reference part number?
A: Yes. RA 312677-KIT supersedes and replaces RA 312677-000. Both part numbers refer to the same component type, but the KIT version incorporates improved hardness and fitment specifications.
Q: What are the thread specifications for RA 312677-KIT?
A: RA 312677-KIT features M16 x 1.5 internal thread specification for tiller arm assembly mounting on Raymond 102T-F45L electric pallet trucks.
Q: How does RA 312677-KIT improve over the older RA 312677-000?
A: RA 312677-KIT provides enhanced surface hardness through induction hardening and offers improved fit tolerance with self-aligning bearings. These upgrades reduce bearing wear and extend stem service life on electric pallet truck steering systems.
Q: Which Raymond models are compatible with RA 312677-KIT?
A: RA 312677-KIT is designed for Raymond 102T-F45L electric pallet truck models. Verify your equipment model designation matches before ordering to ensure correct fitment.
