Product Description
Raymond RA 360-049 Bumper Pad is an OEM steer arm assembly component for Model 101 Walkie electric lift trucks. Manufactured from durable rubber compound, provides impact absorption for steering mechanism protection. Nominal dimensions are 2.75 x 1.12 x 0.75 inches. Includes mounting hole with 0.28 inch diameter. Compatible exclusively with Raymond Model 101 Walkie, S/N 3000–7499.
Compatibility: Fits pallet jacks made by Raymond, model 101. SKU: RA 360-049
Specifications
Electrical Specifications
| Electrical Rating | Not applicable |
Material & Construction
| Finish | Uncoated rubber |
Mechanical Specifications
| Mounting Location | Steer Arm Assembly - Model 101 Walkie |
| Durometer Hardness | Shore A 60 ±5 |
| Operating Position | Fixed mount |
Part Numbers & Compatibility
| OEM Part Number | 360-049 |
| Manufacturer Part Number | RA 360-049 |
| Alternate Part Number | RA360-049 |
| Cross-Reference Part Numbers | Alternate identifiers: 360-049, RA360-049 |
| Compatible Models | Raymond Model 101 Walkie (serial number range: 3000 to 7499) |
Frequently Asked Questions
Q: What is the RA 360-049 and what does it do?
A: The RA 360-049 is a bumper pad and steer arm assembly component for Raymond Model 101 Walkie electric lift trucks. It absorbs impact and protects the steering mechanism from collision damage.
Q: What are the dimensions of the RA 360-049 bumper pad?
A: The RA 360-049 has nominal dimensions of 2.75 x 1.12 x 0.75 inches with a mounting hole diameter of 0.28 inches. Verify these dimensions against your steer arm assembly before ordering.
Q: Which Raymond models are compatible with the RA 360-049?
A: The RA 360-049 is designed exclusively for Raymond Model 101 Walkie electric lift trucks with serial numbers in the range 3000 to 7499. Verify your equipment serial number before ordering.
Q: What material is the RA 360-049 made from?
A: The RA 360-049 is manufactured from a durable rubber compound that provides impact absorption and protects the steer arm assembly from shock loads during operation.
Q: What are the cross-reference part numbers for the RA 360-049?
A: The RA 360-049 has the OEM part number 360-049. Alternate identifiers include RA360-049 and 360-049. All reference the same component. Verify the serial range 3000 to 7499 for Model 101 compatibility.
