Seal Kit for Raymond 101
RA 030-504-008-003
Couldn't load pickup availability
- Expert support & fitment help
- 30-day returns
- Fast Shipping
Compatibility
|
Make |
|
|---|---|
|
Model |
|
Visit our diagram page for part references to popular models
Product Description
Raymond RA 030-504-008-003 Hydraulic Cylinder Seal Kit is engineered for precise fitment in Raymond 101 Electric Lift Truck hydraulic applications. Manufactured to OEM specifications for bore diameters of 2.50 inches and rod diameters of 1.25 inches, the kit uses nitrile rubber and PTFE seals rated for hydraulic pressures up to 3000 PSI. Designed for tilt and lift cylinder sealing, the kit ensures longevity and leak resistance under demanding warehouse conditions.
Compatibility: Fits pallet jacks made by Raymond, model 101. SKU: RA 030-504-008-003
Specifications
Part Numbers & Compatibility
| Make | Raymond |
| Model | 101 |
| Seal Kit Application | Hydraulic Cylinder—tilt/lift function for Raymond 101 series |
| Part Number | RA 030-504-008-003 |
| Manufacturer Part Number | RA 030-504-008-003 |
| Application Environment | Designed for demanding warehouse conditions |
Wheel Dimensions
| Rod Diameter | 1.25 inches |
Performance Specifications
| Hydraulic Pressure Rating | Up to 3000 PSI |
Additional Specifications
| Seal Kit Fitment | Precise fit for Raymond 101 hydraulic cylinder—OEM tolerances |
| Material Specification | Sealing components: nitrile rubber (NBR), Teflon (PTFE) backup rings |
| Seal Hardness | 70 Shore A (NBR lip seals); Teflon backup rings to ASTM D543 |
Frequently Asked Questions
Q: What equipment does the RA 030-504-008-003 seal kit fit?
A: The RA 030-504-008-003 is designed for use in Raymond 101 electric lift truck hydraulic cylinders. It fits tilt and lift cylinder applications on Raymond 101 series equipment.
Q: What sealing materials does the RA 030-504-008-003 kit contain?
A: The RA 030-504-008-003 uses nitrile rubber and ptfе sealing elements. These materials are designed for hydraulic fluid compatibility, providing primary static and dynamic sealing while preventing extrusion under pressure.
Q: What symptoms indicate the RA 030-504-008-003 seals need replacement?
A: Replace the RA 030-504-008-003 seals when you notice visible hydraulic leakage from cylinder rod ends, sluggish tilt or lift response, or noise during mast actuation. Degraded seals can lead to internal bypass and pressure loss.
Q: What is the recommended replacement guidance for the RA 030-504-008-003 seal kit?
A: Always replace the RA 030-504-008-003 seal kit as a complete set to ensure proper sealing performance. Follow the manufacturer's guidelines for installation and maintenance procedures.
Q: What is the expected lifespan of the RA 030-504-008-003 seal kit?
A: The RA 030-504-008-003 typically provides reliable service for 3 to 5 years under normal warehouse conditions. Lifespan depends on factors such as hydraulic fluid cleanliness, operating pressure cycles, and environmental conditions.
