Pump and Motor Assembly for Raymond Electric Pallet Trucks
RA 560-213
Guaranteed Fit. If it doesn’t fit equipment that matches the listing on this page, we’ll exchange or refund it: no restocking fee, return shipping on us. How it works
Not sure it fits? Check it with us before you buy. Once we confirm the fit in writing, it’s guaranteed for your machine.
Couldn't load pickup availability
- Expert support & fitment help
- 30-day returns
- Fast Shipping
Compatibility
|
Make |
|
|---|---|
|
Model |
|
Visit our diagram page for part references to popular models
Product Description
Raymond RA 560-213 Pump and Motor Assembly is a 24VDC integrated drive unit designed for OEM installation on Raymond electric pallet trucks, combining a direct mount series-wound DC traction motor with a factory-coupled hydraulic pump.
Compatibility: Fits pallet jacks made by Raymond, model 101. SKU: RA 560-213
Specifications
Part Numbers & Compatibility
| Make | Raymond |
| Model | 101 |
| Part Number | RA 560-213 |
| Superseded Part Numbers | RA 560-213-03 (Motor Assembly), RA 560-213-07 (Brush Kit), RA 560-213-06 (Starter Solenoid) |
| Compatibility | Fits pallet jacks made by Raymond, model 101. |
Electrical Specifications
| Motor Voltage | 24VDC |
| Control Voltage | 24VDC (main power supply for both pump and motor functions) |
Frequently Asked Questions
Q: What model is the RA 560-213 compatible with?
A: The RA 560-213 is designed for use on Raymond electric pallet trucks models. It is not compatible with the Raymond 101 Series.
Q: What materials are used in the RA 560-213 assembly?
A: The RA 560-213 contains a series-wound DC motor with carbon brushes, copper windings, and a ferrous core. The hydraulic pump section uses cast iron or aluminum housings with internal gearing.
Q: How can I replace or service parts within the RA 560-213 assembly?
A: Individual components such as the motor, brush kit, and starter solenoid can be replaced separately. Related part numbers include RA 560-213-03 (Motor Assembly), RA 560-213-07 (Brush Kit), and RA 560-213-06 (Starter Solenoid).
Q: What is the function of the RA 560-213 pump and motor assembly?
A: The RA 560-213 is a 24VDC integrated drive unit that combines a series-wound DC traction motor with a factory-coupled hydraulic pump. It is used for propulsion and lifting functions in Raymond electric pallet trucks.
Q: What voltage does the RA 560-213 operate on?
A: The RA 560-213 operates at 24VDC for both motor traction and control voltage. The main power supply and control circuits use 24VDC, with the control voltage managing pump and motor functions.
