Product Description
Raymond OEM fuse RA 590-587-113, 250 amp capacity, designed for electric lift truck applications including 8300, 8400, and 8500 Series. Molded phenolic base, bolt-on tin-plated copper terminals, rated for 48VDC main circuit protection. No cross-reference or superseding numbers provided. Manufactured to ANSI/NEMA industrial fuse standards.
Compatibility: Fits pallet jacks made by Raymond, model 8300, 8400, 8500. SKU: RA 590-587-113
Specifications
Electrical
| Rated Current | 250A continuous |
| Rated Voltage | 48VDC maximum |
| Terminal Type | Bolt-on blade, 2-hole mounting |
| Body Material | Molded phenolic insulating base |
Part Numbers
| OEM Part Number | RA 590-587-113 |
| Compatible Models | Raymond 8300, 8400, 8500 Series |
Performance
| Continuous Duty Cycle | 100% duty at rated load; non-cycling application |
| Service Factor | 1.00 |
Frequently Asked Questions
Q: Which Raymond lift truck models use the RA 590-587-113 fuse?
A: The RA 590-587-113 is compatible with Raymond electric pallet jacks and lift trucks in the 8300, 8400, and 8500 series. Verify that your model falls within these series before ordering.
Q: What is the rated current and voltage for the RA 590-587-113?
A: The RA 590-587-113 is rated for 250 amperes continuous at 48VDC maximum. It is designed for main circuit protection in 48-volt battery systems used in Raymond electric lift trucks.
Q: What mounting configuration does the RA 590-587-113 have?
A: The RA 590-587-113 features bolt-on blade terminals with 2-hole mounting. The body is molded phenolic insulating material with tin-plated copper terminals rated for 48VDC applications.
Q: Is the RA 590-587-113 rated for cyclic or continuous duty?
A: The RA 590-587-113 is rated for 100% duty cycle at its rated load and is designed for non-cyclic applications. This means it can handle continuous, sustained current draw without cycling on and off.
Q: Does the RA 590-587-113 have published cross-reference numbers?
A: The RA 590-587-113 does not have published cross-reference or superseding part numbers available. Order using the exact OEM part number to ensure correct fitment in your Raymond equipment.
