Raymond

RA 590-587-118

  • RA 590-587-118, Fuse, 40amp
$1.24 off

RA 590-587-118

Fuse, 40amp

$16.04
$16.04 $17.28
In stock
⚠️ Compatibility Recommended Before Purchase
Electric motors are model-, voltage-, rotation-, mounting-, shaft-, and sometimes serial-number specific. Installing an incompatible motor may result in equipment damage, electrical damage, or unsafe operation.

Before ordering, confirm:
  • Equipment make and model
  • Serial number (if applicable)
  • Operating voltage
  • Rotation direction (CW / CCW)
  • Shaft diameter and length
  • Mounting pattern and flange type

If you’re unsure, contact us before purchasing with your equipment details.

Non-Refundable Item: Motors are non-refundable. Please verify compatibility before purchasing.

Questions? Call +1-800-669-7554
8300 8400 8500 8600 Battery Connector Electric Lift Truck Parts Electrical Fuses Motor Controllers Raymond

Compatibility

Make Raymond
Model 8300, 8400, 8500

Reference Diagrams

Visit our diagram page for part references to popular models

Product Description

Raymond RA 590-587-118 is an OEM 40 amp fuse engineered for main power and control circuit protection in Raymond electric pallet trucks, compatible with 8300, 8400, and 8500 series. This bolt-in DC-rated fuse ensures reliable circuit interruption for electric lift truck systems.

Compatibility: Fits pallet jacks made by Raymond, model 8300, 8400, 8500. SKU: RA 590-587-118

Specifications

Electrical
Fuse Continuous Current Rating40 ampere (40A)
Voltage TypeDC circuit protection
ApplicationMain power fuse for electric pallet trucks
Material & Construction
Body MaterialHigh-dielectric insulating body
Part Numbers
OEM Part NumberRA 590-587-118
Manufacturer Part Number590-587-118
Compatible Equipment ModelsRaymond 8300, 8400, 8500 Series

Frequently Asked Questions

Q: What is the amperage rating for the RA 590-587-118 fuse?
A: The RA 590-587-118 is rated for 40 amperes continuous. It is engineered for main power and control circuit protection in Raymond electric pallet trucks.

Q: Which Raymond pallet jack models use the RA 590-587-118?
A: The RA 590-587-118 is compatible with Raymond electric pallet jacks in the 8300, 8400, and 8500 series. Verify your specific model number before ordering to ensure correct fitment.

Q: Is the RA 590-587-118 for AC or DC applications?
A: The RA 590-587-118 is rated for DC circuit protection. It is designed as the main power fuse for electric pallet truck systems that operate on direct current supplied by onboard batteries.

Q: What material construction does the RA 590-587-118 have?
A: The RA 590-587-118 features a high-die-cast body material for durability and heat dissipation in industrial environments. This construction protects against thermal stress and mechanical wear in electric lift truck applications.

Q: What is the bolt-in fuse mounting style?
A: The RA 590-587-118 is a bolt-in style fuse that mounts directly to the circuit board or fuse holder using terminal connections. This design ensures reliable contact and security in the electrical system.
