Raymond

RA 1-030-007

  • RA 1-030-007, Terminal Strip

RA 1-030-007

Terminal Strip 8-Position Electrical Distribution

$12.51
$12.51 $12.14
In stock
⚠️ Compatibility Recommended Before Purchase
Electric motors are model-, voltage-, rotation-, mounting-, shaft-, and sometimes serial-number specific. Installing an incompatible motor may result in equipment damage, electrical damage, or unsafe operation.

Before ordering, confirm:
  • Equipment make and model
  • Serial number (if applicable)
  • Operating voltage
  • Rotation direction (CW / CCW)
  • Shaft diameter and length
  • Mounting pattern and flange type

If you’re unsure, contact us before purchasing with your equipment details.

Non-Refundable Item: Motors are non-refundable. Please verify compatibility before purchasing.

Questions? Call +1-800-669-7554
8300 8400 8500 8600 Battery Connector Electric Lift Truck Parts Electrical Motor Controllers Raymond

Compatibility

Make Raymond
Model 8300, 8400, 8500, 8900

Reference Diagrams

Visit our diagram page for part references to popular models

Product Description

The Raymond RA 1-030-007 terminal strip is a heavy-duty electrical distribution component designed for electric pallet jacks in the Raymond 8300, 8400, 8500, and 8900 series. This panel-mount terminal block features 8 screw-clamp positions rated at 30A per terminal, with tin-plated brass contacts for reliable connectivity. The flame-retardant phenolic base resists oils, moisture, and thermal stress common in material handling operations.

Specifications

Compatibility
Compatible Equipment ModelsRaymond 8300, 8400, 8500 series electric pallet trucks
Dimensional
Terminal Spacing0.375 inch (center-to-center)
Electrical
Rated Voltage150VDC maximum
Rated Current Capacity30A per position
Number of Terminals8 positions
Material & Construction
Base MaterialThermoset phenolic resin, flame-retardant per ASTM D635
Terminal MaterialTin-plated brass
Part Numbers
OEM Part NumberRA 1-030-007
Performance
Service Factor1.0 (industrial continuous duty)

Frequently Asked Questions

Q: What is the Raymond RA 1-030-007 terminal strip used for?
A: The RA 1-030-007 is an OEM terminal strip for primary electrical distribution in Raymond electric pallet trucks. It features 8 screw-clamp terminal positions that consolidate multiple electrical circuits onto a single panel-mount component.

Q: Which Raymond pallet truck models use the RA 1-030-007?
A: The RA 1-030-007 is compatible with Raymond 8300, 8400, and 8500 series electric pallet trucks. Verify your truck model number matches one of these series before ordering.

Q: What are the electrical specifications of the RA 1-030-007?
A: The RA 1-030-007 is rated 150VDC maximum with 30A per terminal position. It features 8 screw-clamp positions on 0.375-inch center-to-center spacing. Terminal material is tin-plated brass, and the base is thermoset phenolic flame-retardant material rated for industrial duty.

Q: What material properties make the RA 1-030-007 suitable for lift truck use?
A: The tin-plated brass contacts resist corrosion and provide reliable electrical connectivity under load. The thermoset phenolic base is flame-retardant and resistant to oils, moisture, and thermal stress common in industrial material handling environments.

Q: How do I determine if the RA 1-030-007 is the correct replacement for my terminal strip?
A: Confirm your truck model is Raymond 8300, 8400, or 8500 series. Measure the terminal spacing (should be 0.375 inch center-to-center) and verify the mounting configuration. Count the terminal positions; the RA 1-030-007 has exactly 8 positions.
