Product Description
Raymond RA 1025349-001 is an OEM polyurethane bushing rated for 8,000 lbs, used in pivot/load wheel assemblies on electric lift trucks including the 8300, 8400, and 8500 series. Material: Polyurethane 95A durometer, bore 0.98 in (25 mm), outer diameter 2.04 in (52 mm), length 2.50 in (63.5 mm). Designed as a direct replacement for specific pivot block and load wheel positions; use with 6205 ball bearings where applicable.
Compatibility: Fits pallet jacks made by Raymond, model 8300, 8400, 8500. SKU: RA 1025349-001
Specifications
Material & Construction
| Material Specification | Polyurethane 95A durometer |
Mechanical Specifications
| Bore Diameter | 0.98 in (25 mm) |
| Outer Diameter | 2.04 in (52 mm) |
| Length | 2.50 in (63.5 mm) |
| Durometer Rating | 95 Shore A |
| Load Capacity | 8,000 lbs |
| Associated Bearing | 6205 (deep groove ball bearing, usually supplied separately) |
Part Numbers
| Part Number | RA 1025349-001 |
| Supersedes Part Numbers | RA 1025349-006, RA 1025349-007 |
Compatibility
| Compatible Equipment | Raymond 8300, 8400, 8500 series electric pallet jacks |
Frequently Asked Questions
Q: What is the RA 1025349-001 bushing and where is it used?
A: The RA 1025349-001 is an OEM polyurethane bushing rated for 8,000 lbs, used in pivot block and load wheel assemblies on Raymond electric lift trucks. The polyurethane material absorbs vibration and reduces noise while supporting rotational and load-bearing functions.
Q: What are the dimensions and material specifications?
A: The RA 1025349-001 has a bore diameter of 0.98 inches (25 mm), outer diameter of 2.04 inches (52 mm), and length of 2.50 inches (63.5 mm). Material is polyurethane at 95A durometer hardness, providing flexibility and abrasion resistance.
Q: Which Raymond models does this bushing fit?
A: The RA 1025349-001 fits Raymond models 8300, 8400, and 8500 series electric pallet jacks. This bushing is compatible with 6205 series ball bearings where specified in related load wheel and pivot assemblies.
Q: What bearings work with this bushing?
A: The RA 1025349-001 is designed to work with 6205 series deep groove ball bearings in related pivot block and load wheel assemblies. The bearing is typically supplied separately and must be verified for your specific application.
Q: Are there superseding or equivalent part numbers?
A: The RA 1025349-001 supersedes part numbers RA 1025349-006 and RA 1025349-007 in certain applications. However, verify cross-compatibility with your exact model and serial range, as these parts may have different load ratings or dimensions.
