Product Description
GW 424 steer wheel axle by Liftsplus.com is a forged steel axle engineered for manual pallet jack steer wheel assemblies. Manufactured from ASTM A29 grade steel with black oxide finish and precision threading, it fits standard bearings and supports up to 40,000 operating cycles. Nominal diameter 0.75 inch, length 2.50 inches. Compatible with multiple manual pallet jack models. No available cross-reference part numbers.
Specifications
Dimensional Specifications
| Clearance Requirement | Requires 0.875 inch minimum fork wall clearance |
Material & Construction
| Hardness | Rockwell C38 minimum |
Mechanical Specifications
| Thread Specification | 1/2"-13 UNC thread at both ends |
Part Numbers & Compatibility
| Manufacturer Part Number | GW 424 |
Frequently Asked Questions
Q: What is the GW 424 steer wheel axle and what equipment does it fit?
A: The GW 424 is a forged steel steer wheel axle manufactured from ASTM A29 grade steel with black oxide finish. It is engineered for manual pallet jack steer wheel assemblies and fits standard pallet jack bearing configurations on multiple equipment brands including Crown, Toyota, Raymond, Yale, and Hyster models.
Q: What are the thread and dimensional specifications for the GW 424?
A: The GW 424 has a nominal diameter of 0.75 inch and length of 2.50 inches. Both ends feature 1/2 inch-13 UNC threads. This standard threading fits common pallet jack bearing housings and allows axle installation without custom modification.
Q: What are the performance specifications and load rating for the GW 424?
A: The GW 424 supports up to 40000 operating cycles, delivering reliability for high-frequency pallet jack operations in warehouse environments. It is manufactured to Rockwell C38 hardness minimum, ensuring durability and resistance to fatigue from repeated steer wheel rotation.
Q: What clearance is required to install the GW 424?
A: Installation requires a minimum fork wall clearance of 0.875 inch to accommodate the axle diameter and bearing assembly. Measure the clearance space on your pallet jack before ordering to confirm compatibility.
Q: How do I replace the GW 424 steer wheel axle?
A: To replace the GW 424, remove the steer wheel assembly and bearing housing from the fork. Unbolt or press out the old axle. Install the new GW 424 axle into the bearings, ensuring threads align properly with the mounting points. Reinstall the wheel assembly and verify smooth steering motion before returning equipment to service.
