Product Description
Industrial strobe light SY MCF00243 for electric lift trucks, compatible with 12-74VDC input. Designed for NEMA 4X environments, featuring impact-resistant polycarbonate lens, robust NPT pipe mounting, and a rated effective light output of 200 candela. Suitable for heavy-duty material handling and warning applications.
Specifications
Electrical
| Operating Voltage | 12-74 VDC voltage input range |
| Current Draw | 1.2A at 12VDC; 590mA at 24VDC; 370mA at 48VDC; 190mA at 80VDC |
| Maximum Inrush Current | 1.75A at 24VDC |
| Candela Rating | Effective intensity 200 candela (Cd-Eff) |
Material & Construction
| Housing Construction | Water-tight and dust-tight enclosure rated for NEMA 4X applications |
Part Numbers
| Manufacturer Part Number | SY MCF00243 |
Performance
| Strobe Flash Rate | 80 single flashes per minute (SFPM) |
Frequently Asked Questions
Q: What voltage range does the SY MCF00243 operate at?
A: The SY MCF00243 operates on a wide 12-74 VDC input range. Current draw varies with voltage: 1.2 A at 12 VDC, 590 mA at 24 VDC, 370 mA at 48 VDC, and 190 mA at 80 VDC. Maximum inrush current is 1.75 A at 24 VDC.
Q: What is the light output specification for the SY MCF00243?
A: The SY MCF00243 has an effective light output of 200 candela (Cd-Eff), providing strong visual warning visibility in indoor and outdoor environments. This brightness level is suitable for high-bay warehouses, loading docks, and congested material handling areas.
Q: Is the SY MCF00243 suitable for wet or harsh environments?
A: Yes. The SY MCF00243 is designed for NEMA 4X environments with a water-tight housing. It features an impact-resistant polycarbonate lens and is suitable for wet areas, cold storage, and outdoor applications where moisture and physical impact are concerns.
Q: How is the SY MCF00243 mounted?
A: The SY MCF00243 uses robust NPT pipe mounting, which is a standard thread connection for industrial strobe applications. Verify your equipment has compatible NPT mounting provisions before ordering.
Q: What is the effective operating life of the SY MCF00243?
A: Industrial strobe lights typically operate 50,000 to 100,000 hours. The SY MCF00243 is built for heavy-duty material handling, but lifespan depends on duty cycle and environment. Replace if the unit fails to activate, flashes irregularly, or output dims significantly.
